Versa-Matic E3 - Repair Parts List - Elastomeric;TPE

e3mdlHsmATEXMB-rev0317
11 • Model E3 Bolted Metallic
ww w.ve rsam atic .com
Notes:
1.) These O-Rings are only needed with the stainless steel valve seat SV456
Composite Repair Parts List - Elastomeric and TPE Fitted
Air Valve Assembly
Item # Qty. Description Aluminum Part Number Stainless Steel Part Number
1 1 Valve Body (includes items 2-11) 031.V003.156 031.V003.110
2 1 Valve Body 095.V001.156 095.V001.110
3 1 Valve Body Gasket P24-202
4 1 Valve Sleeve 755.V005.148
5 6 O-ring 560.206.360
6 1 Valve Spool Assembly (Includes items 7) 775.V001.000
7 6 Glyde Ring Assembly P34-204F
8 1 Air Valve Screen P24-210 P34-210
9 2 End Cap Gasket P24-205
10 2 End Cap P34-300
11 13 Mounting Screws (8 included on item 1) S1001
Center Section Assembly
Item # Qty. Description Aluminum Part Number Stainless Steel Part Number
12 1 Center Block Assembly (Includes item 13 & 14) P34-400DC ASY SP34-400
13 2 Bearing Sleeve P34-404
14 2 Main Shaft O-Ring P34-403
15 2 Air Chamber 196.V008.157 196.V006.110
16 2 Air Chamber Gasket P79-109 P24-109A
17 8 Bolt P24-110
18 1 Pilot Sleeve Assembly (include item 19) 755.V002.000
19 6 O-ring 560.101.358
20 1 Retaining Ring 675.037.080
21 1 Pilot Spool Assembly (Includes item 22) 775.V006.000
22 8 O-ring 560.023.358
23 1 Mufer 530.033.000
Diaphragm Assembly / Elastomers
Item # Qty. Description
Part Number
Versa-Rugged Versa-Dome
24 1 Main Shaft P34-103
25 2 Diaphragm (See Below Material Chart) V305xx V306xx
26 2 Outer Diaphragm Plate SV302B SVB307
27 2 Inner Diaphragm Plate V302CDC V307B
28 12 Bolt V302G N/A
29 12 Washer V302GA N/A
30 2 Bumper Washer P34-501
31 2 Back-Up Washer V302E
32 4 Valve Seat (See Below Material Chart) V456xx
33 4 Valve seat O-Ring (See Note 1) SV456TES-1
34 4 Valve seat O-Ring (See Note 1) SV456TES-2
35 4 Valve Ball (See Below Material Chart) V455xx
Wet End Assembly
Item # Qty. Description Part Number
36 2 Water Chamber SV350FB
37 36 Bolt SV387A
38 36 Nut SV387C
39 36 Washer SV387B
40
2 Discharge Manifold SV351FB
1 Discharge Drop in Manifold 518.V002.110
1 Discharge Drop in Manifold (BSP) 518.V002.110 E
41
1 Suction Manifold SV352FFB
1 Suction Drop in Manifold 518.V003.110
1 Suction Drop in Manifold (BSP) 518.V003.110 E
1 Suction WD Drop in Manifold 518.V003.110 W
1 Suction WD Drop in Manifold (BSP) 518.V003.110 WE
Elastomer Material Specications
Material Versa-Rugged Diaphragm P/N Versa-Dome Diaphragm P/N "Ball P/N" Seat P/N
Neoprene V305N V306N V455N V456N
Nitrile V305BN V306BN V455BN V456BN
FKM V305VT V306VT V455VT V456VT
EPDM V305ND V306ND V455ND V456ND
PTFE N/A N/A V455TF V456TF
Santoprene V305TPEXL N/A V455TPEXL V456TPEXL
Hytrel V305TPEFG N/A V455TPEFG V456TPEFG
Geolast V305G N/A N/A N/A
Stainless Steel N/A N/A N/A SV456 (see note 1)
MODEL SPECIFIC
3: EXP VIEW
