39014-03 06/16VERSALIFT VST-36/40/47/52-I
SPECIFICATIONS
VST-40-I DIMENSIONAL SPECIFICATIONS
Based on 40 in (1.02 m) Frame Height, all Dimensions Nominal
Horizontal Reach ................................................................................................................ 30 ft 2 in (9.2 m)
Maximum Platform Capacity (varies with installation and jib/winch) ...................................600 lbs. (272 kg)
Jib Capacity (varies with boom position) ..........................................................................1000 lbs. (454 kg)
With 46.25 in (1.17 m) Tall Pedestal (Standard)
Height to Bottom of Platform ............................................................................................ 40 ft 4 in (12.3 m)
Working Height................................................................................................................. 45 ft 4 in (13.8 m)
Stowed Travel Height ......................................................................................................... 10 ft 6 in (3.2 m)
Weight of Lift .................................................................................................................3,300 lbs. (1495 kg)
With 52.25 in (1.33 m) Tall Pedestal (6 in taller)
Height to Bottom of Platform .......................................................................................... 40 ft 10 in (12.4 m)
Working Height............................................................................................................... 45 ft 10 in (14.0 m)
Stowed Travel Height ......................................................................................................... 11 ft 0 in (3.4 m)
Weight of Lift .................................................................................................................3,320 lbs. (1505 kg)
With 58.25 in (1.48 m) Tall Pedestal (12 in taller)
Height to Bottom of Platform ............................................................................................ 41 ft 4 in (12.6 m)
Working Height................................................................................................................. 46 ft 4 in (14.1 m)
Stowed Travel Height ......................................................................................................... 11 ft 6 in (3.5 m)
Weight of Lift .................................................................................................................3,340 lbs. (1515 kg)
With 64.25 in (1.63 m) Tall Pedestal (18 in taller)
Height to Bottom of Platform .......................................................................................... 41 ft 10 in (12.8 m)
Working Height............................................................................................................... 46 ft 10 in (14.3 m)
Stowed Travel Height ................................................................................................................ 12 ft (3.7 m)
Weight of Lift .................................................................................................................3,360 lbs. (1525 kg)
Hydraulic System
Operating Pressure ....................................................................................................3000 psi (210 kg/cm
2
)
Flow Rate .......................................................................................................................... 6 gpm (22.7 lpm)
Filtration ............................................................................................................................ 10 micron Return
100 mesh Suction
System Type ............................................................................................................................. Open Center
Power Source ..............................................................................................................................PTO Pump
Boom Action
Outer/Inner Boom Travel ............................................................................................................ -25
0
to +85
0
Lower Boom Travel ....................................................................................................................... 0
0
to +87
0
Inner Boom Extension ............................................................................................................ 103 in (2.6 m)
Rotation ............................................................................................................................ 360
o
Continuous.
Insulation Gap
Upper Boom Fully Retracted .................................................................................................... 46 in (1.2 m)
Lower Boom ......................................................................................................................... 12 in (305 mm)
Ambient Temperature Range for Structural Integrity ............................... -40°F (-40°C) to 125°F (52°C)
