VERSE SUB Series - Connection Examples; Power and Signal Cabling

SUB User's Guide
13
14
13. AC−IN powercon: connect the mains cable supplied from the factory with the
loudspeaker to this socket.
14. AC POWER OUT: easily connect another VERSE speaker to the mains. Pay attention
not to exceed the current limit reported on the chassis near the grey connector.
The Powercon connectors make the system very practical and, thanks to the LINK
OUTPUT on each enclosure, avoid the problem of having to run a power feed to each
element.
All VERSE Systems are provided with special customized cables made of a pair of
powercons and balanced XLR connectors. Therefore it is possible to provide for
signal and power a VERSE Insider from another VERSE Insider or a VERSE Sub.
Subwoofers feature a double output link to simplify the left and right audio channels.
Please note: the purchase of a spare VERSE speaker (i.e: not buying it in a −k system)
doesn't include the customized cables.
The customized cable provided with
VERSE speakers.
Detail of a Powercon
main input
