VXA-210 PILOT OPERATING MANUAL
26
MEMORY OPERATION
The VXA-210 provides 50 user-programmable
“Main” memories, labeled “CH
-
001” through
“CH
-
050,” and up to 100 pre-programmed memo-
ries, designated “Book” Memories. The “ ” icon
appears when “Book” Memory Mode is activated.
The Main memories and “Book” Memories can be
assigned alpha-numeric names of up to eight charac-
ters.
Memory System Operation
The VXA-210’s Main Memory system allows the
user to store, label, and recall channel frequencies
which you may want to use frequently. You may store
VFO frequencies, Book Memory frequencies, and/
or Weather Channel frequencies (USA version only)
into the Main Memory system.
Memory Storage
r Select the desired frequency in the VFO mode,
or recall the Book Memory channel or Weather
channel to be stored in the Main Memory.
r Press and hold the
[
MW
(
SPL.W
)]
key for 2
seconds. The display will indicate “CH
-
” and a
channel number will blink on the LCD.
r Within five seconds of pressing the
[
MW
(
SPL.W
)]
key, rotate the DIAL selector knob to
select the desired memory channel number for
storage.
In order to prevent writing over memory chan-
nels, a bar will appear under the hyphen (located
between “CH” and the channel number) to indi-
cate a vacant memory channel.
r Now press and hold in the
[
MW
(
SPL.W
)]
key
for 2 seconds; you will now see “
- - - - - - - -
” on the
LCD. To attach an alpha/numeric name (label)
to the memory, proceed to the next step; other-
wise press and hold
[
MW
(
SPL.W
)]
for 2 sec-
onds to save the entry and exit.
r To label a memory with an alpha/numeric name,
the next step is to use the DIAL selector knob to
select any of the 48 available characters (includ-
ing letters, numbers, and special symbols). When
