VXA-210 PILOT OPERATING MANUAL
27
the desired first character appears, press the DIAL
selector knob momentarily to move on to the next
character.
r Select succeeding characters in the same man-
ner, pressing the DIAL selector knob momentarily
after each selection.
r After entering the entire name (eight characters
maximum), press the
[
MW
(
SPL.W
)]
key for 2
seconds to save all data for the channel and exit.
Note: If you have stored a Weather Channel, the
“WX
-
001 ~ WX
-
010” labels utilize the alphanu-
meric memory, and other labels may not be stored.
Recalling the Memories
r Press the DIAL selector knob, repeatedly if nec-
essary, until “MR” (Memory Recall) appears on
the display. In the MR mode, you will see “CH
-
”
and the previously selected channel number ap-
pearing on the LCD.
r Rotate the DIAL selector knob to select the de-
sired memory channel.
r You may change the title structure of the Memory
display type among:
1. Channel Indication (sequential Channel Number,
e.g. CH
-
001, CH
-
002, etc.);
2. Frequency Indication (e.g. 122.500); or
3. Alphanumeric Label (e.g. LAX FSS).
r To change the Memory display title, press the
[
( )]
key repeatedly, if necessary, until you
get the desired display title structure.
r To exit the Memory mode, press the DIAL selector
knob momentarily to return to the VFO mode.
Note: In either the “MR” or the “Book” Memory
mode, you can change memory channels in 10 chan-
nel steps: press the
[
F
]
key momentarily, then rotate
the DIAL selector knob. The “ ” icon will show at
the right edge of the display when the 10 channel step
tuning mode is active. Press the
[
F
]
key once more to
resume normal channel selection in 1 channel steps.
MEMORY OPERATION
Alpha-tag Charactors
0 1 2 3 4 5 6 7 8 9 A B
C D E F G H I J K L M N
O P Q R S T U V W X Y Z
< > +
-
Û / D µ S | -
