VXA-210 PILOT OPERATING MANUAL
48
SPECIFICATIONS
General
Frequency Range: TX: 118.000 - 136.975 MHz, RX: 108.000 - 136.975 MHz,
Weather Channels (WX-01 - WX-10: USA version only)
Channel Spacing: 25 kHz
Emission Type: TX: AM,
RX: AM & FM (FM: for receiving the Weather Channels, USA version only)
Supply Voltage: 6.0 - 15.0 VDC
Current Consumption (approx.): 10 µA (power off), 30 mA (battery saver on, saver ratio 1:5)
65 mA (squelch on), 190 mA (receive), 1 A (transmit 1.5 W Carrier)
Temperature Range: +14 °F to + 140 °F (–10 °C to +60 °C)
Case Size (WxHxD): 2.3 x 4.3 x 1.2 inch (58 x 109 x 30 mm) w/FNB-64
Weight (approx.): 12.2 oz (345 grams) with FNB-64, antenna, and belt clip
Receiver
Circuit Type: Double-conversion superheterodyne
IFs: 35.4 MHz & 450 kHz
Sensitivity: <0.8 µV (for 6 dB S/N with 1 kHz, 30 % modulation)
Selectivity: >8 kHz/–6 dB
Adjacent CH. Selectivity: <25 kHz/–60 dB
AF Output (@7.2 V): 0.4 W @ 8 Ohms, 10 % THD
Transmitter
Power Output (@ 7.2 V): 5 W (PEP), 1.5 W (Carrier Power)
Frequency Stability: Better than ±10 ppm (+14 °F to + 140 °F [–10 °C to +60 °C])
Modulation System: Low Level Amplitude Modulation
Spurious Emission: >60 dB below carrier
Int. Microphone Type: Condenser
Ext. Mic. Impedance: 150 Ohms
Specifications are subject to change without notice or obligation.
