Vertex Standard VX-146 Service Manual

20
REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR
MAIN Unit Parts List
R 1066 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B e1
R 1067 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A A1
R 1068 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B f2
R 1069 CHIP RES. 22k 1/16W 5% RMC1/16S 223JTH J24189041 1- B f2
R 1070 CHIP RES. 5.6k 1/16W 5% RMC1/16S 562JTH J24189034 1- A A1
R 1071 CHIP RES. 1.8M 1/16W 5% RMC1/16S 185JTH J24189064 1- A A1
R 1072 CHIP RES. 27k 1/16W 5% RMC1/16S 273JTH J24189042 1- A A1
R 1073 CHIP RES. 1.8k 1/16W 5% RMC1/16S 182JTH J24189028 1- A A1
R 1074 CHIP RES. 1.5M 1/16W 5% RMC1/16S 155JTH J24189063 1- A A1
R 1075 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A B1
R 1076 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B a2
R 1077 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B a2
R 1078 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- B a2
R 1079 CHIP RES. 470 1/16W 5% RMC1/16S 471JTH J24189021 1- B a2
R 1080 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- B c1
R 1081 CHIP RES. 10 1/16W 5% RMC1/16S 100JTH J24189001 1- B c1
R 1084 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- B c1
R 1085 CHIP RES. 5.6k 1/16W 5% RMC1/16S 562JTH J24189034 1- B c1
R 1086 CHIP RES. 4.7 1/16W 5% RMC1/16S 4R7JTH J24189066 1- B c1
R 1087 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- A A2
R 1088 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- A A2
R 1089 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- A A2
R 1090 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- A B1
R 1091 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- A B1
R 1092 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- A B2
R 1093 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B e1
R 1094 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B e1
R 1095 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B e1
R 1096 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B e1
R 1097 CHIP RES. 39k 1/16W 5% RMC1/16S 393JTH J24189044 1- B f1
R 1098 CHIP RES. 82k 1/16W 5% RMC1/16S 823JTH J24189048 1- B f1
R 1099 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B f1
R 1100 CHIP RES. 470 1/16W 5% RMC1/16S 471JTH J24189021 1- B f1
R 1101 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- B f1
R 1102 CHIP RES. 15k 1/16W 5% RMC1/16S 153JTH J24189039 1- A B1
R 1103 CHIP RES. 220 1/16W 5% RMC1/16S 221JTH J24189017 1- B a2
R 1105 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- B b1
R 1106 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- B c1
R 1107 CHIP RES. 6.8k 1/16W 5% RMC1/16S 682JTH J24189035 1- B c1
R 1108 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A E1
R 1109 CHIP RES. 330 1/16W 5% RMC1/16S 331JTH J24189019 1- A F1
R 1110 CHIP RES. 470 1/16W 5% RMC1/16S 471JTH J24189021 1- A F1
R 1111 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A F2
R 1112 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- B f2
R 1113 CHIP RES. 3.3k 1/16W 5% RMC1/16S 332JTH J24189031 1- B f3
R 1114 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B e3
R 1116 CHIP RES. 3.3k 1/16W 5% RMC1/16S 332JTH J24189031 1- B f2
R 1117 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B b1
R 1120 CHIP RES. 0.33 1/8W 10% RMC1/8 R33KTP J24219001 1- A E1
R 1121 CHIP RES. 0.33 1/8W 10% RMC1/8 R33KTP J24219001 1- A E1
R 1122 CHIP RES. 390 1/16W 5% RMC1/16S 391JTH J24189020 1- A C2
R 1123 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A C2
R 1124 CHIP RES. 390 1/16W 5% RMC1/16S 391JTH J24189020 1- A C2
R 1125 CHIP RES. 27k 1/16W 5% RMC1/16S 273JTH J24189042 1- B d1
R 1126 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- B c1
R 1127 CHIP RES. 22k 1/16W 5% RMC1/16S 223JTH J24189041 1- B d1
R 1128 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- A C1
R 1129 CHIP RES. 6.8k 1/16W 5% RMC1/16S 682JTH J24189035 1- B c1
R 1130 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B e2
R 1131 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- B f2
R 1132 CHIP RES. 3.3k 1/16W 5% RMC1/16S 332JTH J24189031 1- B e3
R 1133 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B e3
R 1135 CHIP RES. 3.3k 1/16W 5% RMC1/16S 332JTH J24189031 1- B e3
R 1136 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B b2
R 1137 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B b2
R 1138 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- B b2
R 1139 CHIP RES. 390 1/16W 5% RMC1/16S 391JTH J24189020 1- B b2
R 1140 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- A E1
R 1141 CHIP RES. 68 1/16W 5% RMC1/16 680JATP J24185680 1- B a1
R 1142 CHIP RES. 68 1/16W 5% RMC1/16 680JATP J24185680 1- B a1
R 1143 CHIP RES. 0.33 1/8W 10% RMC1/8 R33KTP J24219001 1- A E1
R 1144 CHIP RES. 180 1/16W 5% RMC1/16S 181JTH J24189016 1- A E1
R 1145 CHIP RES. 27k 1/16W 5% RMC1/16S 273JTH J24189042 1- A E1
R 1146 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B e2
R 1147 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B b2
R 1148 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- A E2
