Vertex Standard VX-146 Service Manual

21
MAIN Unit Parts List
REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR
R 1149 CHIP RES. 22 1/16W 5% RMC1/16S 220JTH J24189005 1- B b3
R 1150 CHIP RES. 390 1/16W 5% RMC1/16S 391JTH J24189020 1- B c2
R 1151 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B c2
R 1152 CHIP RES. 8.2k 1/16W 5% RMC1/16S 822JTH J24189036 1- A E1
R 1153 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- A E2
R 1154 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- A E2
R 1155 CHIP RES. 220 1/16W 5% RMC1/16S 221JTH J24189017 1- A E2
R 1156 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A E2
R 1158 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- A E1
R 1159 CHIP RES. 390 1/16W 5% RMC1/16S 391JTH J24189020 1- A E2
R 1160 CHIP RES. 3.9k 1/16W 5% RMC1/16S 392JTH J24189032 1- A E2
R 1161 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A A1
R 1162 CHIP RES. 22k 1/16W 5% RMC1/16S 223JTH J24189041 1- A A2
R 1163 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- A A1
R 1164 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B e1
R 1165 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- A A3
R 1167 CHIP RES. 22k 1/16W 5% RMC1/16S 223JTH J24189041 1- A E2
R 1168 CHIP RES. 220 1/16W 5% RMC1/16 221JATP J24185221 1- A E2
R 1169 CHIP RES. 15k 1/16W 5% RMC1/16S 153JTH J24189039 1- B e2
R 1170 CHIP RES. 6.8k 1/16W 5% RMC1/16S 682JTH J24189035 1- B f2
R 1171 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B c2
R 1172 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- A A2
R 1173 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- A A2
R 1174 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- A A3
R 1175 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- A E2
R 1176 CHIP RES. 18k 1/16W 5% RMC1/16S 183JTH J24189040 1- A A3
R 1177 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- A A2
R 1178 CHIP RES. 220 1/16W 5% RMC1/16 221JATP J24185221 1- A E2
R 1179 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- A E2
R 1181 CHIP RES. 2.2 1/16W 5% RMC1/16 2R2JATP J24185229 1- A F2
R 1182 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- A F2
R 1183 CHIP RES. 2.7k 1/16W 5% RMC1/16S 272JTH J24189030 1- B c2
R 1185 CHIP RES. 150k 1/16W 5% RMC1/16S 154JTH J24189051 1- B c2
R 1186 CHIP RES. 3.3k 1/16W 5% RMC1/16S 332JTH J24189031 1- B d2
R 1187 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- A A2
R 1188 CHIP RES. 120k 1/16W 5% RMC1/16S 124JTH J24189050 1- A A2
R 1189 CHIP RES. 150k 1/16W 5% RMC1/16S 154JTH J24189051 1- A A2
R 1190 CHIP RES. 470k 1/16W 5% RMC1/16S 474JTH J24189057 1- B d2
R 1191 CHIP RES. 680 1/16W 0.5% RR0510P-681-D J24189115 1- A A2
R 1192 CHIP RES. 100k 1/16W 0.5% RR0510R-104-D J24189167 1- A A3
R 1193 CHIP RES. 470k 1/16W 5% RMC1/16S 474JTH J24189057 1- A A2
R 1194 CHIP RES. 2.2M 1/16W 5% RMC1/16S 225JTH J24189065 1- A A3
R 1195 CHIP RES. 100k 1/16W 0.5% RR0510R-104-D J24189167 1- A A2
R 1196 CHIP RES. 33k 1/16W 5% RMC1/16S 333JTH J24189043 1- A A3
R 1197 CHIP RES. 68k 1/16W 5% RMC1/16S 683JTH J24189047 1- A A2
R 1198 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B e1
R 1199 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- A C1
R 1200 CHIP RES. 470 1/16W 5% RMC1/16S 471JTH J24189021 1- A C1
R 1201 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- A C1
R 1202 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- A C1
R 1203 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A D2
R 1204 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A D2
R 1205 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- B c2
R 1206 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- B c2
R 1207 CHIP RES. 1.5k 1/16W 5% RMC1/16S 152JTH J24189027 1- B c2
R 1208 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- A A2
R 1210 CHIP RES. 22k 1/16W 0.5% RR0510R-223-D J24189151 1- A A2
R 1211 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- A A2
R 1212 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- A A2
R 1213 CHIP RES. 10k 1/16W 0.5% RR0510P-103-D J24189143 1- A B2
R 1215 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B f1
R 1216 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A D3
R 1217 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- A E2
R 1218 CHIP RES. 33k 1/16W 5% RMC1/16S 333JTH J24189043 1- B e3
R 1221 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B e3
R 1222 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B f2
S 1001 ROTARY SWITCH EC10SP16-85A0 Q9000764 1- B a2
S 1002 TACT SWITCH SKHLLD N5090066 1- B b1
S 1003 TACT SWITCH SKHLLD N5090066 1- B c1
TH1001 THERMISTOR TBPS1R103K440H5Q G9090067 1- B d1
VR1001 POT. RK0971111 20KA/SW J60800256 1- B a3
X 1001 XTAL SX-2112 14.6MHz 14.6MHZ H0103260 1- B d2
X 1002 XTAL SX-1319 3.6864MHz 3.6864MHZ H0103214 1- B e1
XF1002 XTAL FILTER HDF0051 44.25M H1102358 1- B b2
SHIELD FINGER 3525 3100103 S5000226 1- A D2
SHIELD FINGER 3525 3100103 S5000226 1- A D2
