Keypad Functions (VX-120)
Key Primary Function
(Press Key)
Secondary Function
(Press [F/W] Key +)
Third Function
(Press and Hold Key)
[WX(∞/EMG)] Recalls the “Weather”
broadcast channel
bank.
Activates the Internet
Connection feature.
Activates the
EMERGENCY
function.
[LOW(SET/LOC
K)]
Selects the desired
transmit power output
level.
Engages the Set
(Menu) Mode.
Activates the Key
Lockout feature.
[▲(MHz)]
Increases the VFO
frequency by one
step or moves the
memory channel to
the next-highest
channel.
Tunes the VFO
frequency upward in
1 MHz steps.
Starts the scanner
upward (toward a
higher frequency or a
higher channel
number).
[▼(MHz)]
Decreases the VFO
frequency by one
step or moves the
memory channel to
the next-lowest
channel.
Tunes the VFO
frequency downward
in 1 MHz steps.
Starts the scanner
downward (toward a
lower frequency or a
lower channel
number).
[REV(HOME] *
2
Reverses the transmit
and receive
frequencies while
working through a
repeater.
Switches to the
“Home” (favorite
frequency) Channel.
None
[MR(SKIP)] Set the frequency
control to the Memory
Recall mode.
Activates the
“Memory “Tune”
mode while in the
Memory Recall mode.
Selects the Memory
Scan “Skip”
channel-selection
mode.
None
[VFO(PRI)] Set the frequency
control to the VFO
mode.
Select the VFO
between “VFO A” and
“VFO B” while in the
VFO mode.
Activates the Priority
(Dual Watch)
function.
Starts the
programmed VFO
scanner upward
while in the VFO
mode.
Select the Memory
Bank while in the
Memory Recall mode.
[F/W] Activates the
“Alternate” key
function.
Disables the
“Alternate” key
function.
Activates the
“Memory Write” mode
(for memory channel
storage).
