100 VX-1700 Series (EXP Version) Service Manual
PA Unit (Lot 1~108)
Parts List
R 2052 CHIP RES. 56 1/2W 5% RMC1/2 560JTE J24275560 1- A B1
R 2053 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A B1
R 2054 CHIP RES. 150 1/16W 5% RMC1/16 151JATP J24185151 1- A I8
R 2057 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1-3 A I1
R 2058 CHIP RES. 0.001 1W TLR3ADTE1L0J J24309042 1 A H1
R 2059 CHIP RES. 180k 1/10W 0.5% RR1220R-184-D-T5 J24209225 1 A I1
R 2060 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1 A I1
R 2061 CHIP RES. 1.5k 1/10W 0.1% RR1220P-152-B J24209078 1 A H1
R 2062 CHIP RES. 1.5k 1/10W 0.1% RR1220P-152-B J24209078 1 A H1
R 2063 CHIP RES. 180k 1/10W 0.5% RR1220R-184-D-T5 J24209225 1 A H1
R 2064 CHIP RES. 4.7k 1/16W 5% RMC1/16 472JATP J24185472 1 A H1
R 2065 CHIP RES. 10k 1/10W 0.1% RR1220P-103-B J24209098 1 A H1
R 2066 CHIP RES. 1.5k 1/10W 0.1% RR1220P-152-B J24209078 1 A I1
R 2067 CHIP RES. 10k 1/10W 0.1% RR1220P-103-B J24209098 1 A I1
R 2068 CHIP RES. 1.5k 1/10W 0.1% RR1220P-152-B J24209078 1 A I1
R 2070 CHIP RES. 0 1/10W 5% RMC1/10T 000J J24205000 1- A C7
R 2071 CHIP RES. 0 1/10W 5% RMC1/10T 000J J24205000 1- A C6
R 2072 CHIP RES. 0 1/10W 5% RMC1/10T 000J J24205000 1- A C5
R 2073 CHIP RES. 0 1/10W 5% RMC1/10T 000J J24205000 1- A C4
R 2074 CHIP RES. 0 1/10W 5% RMC1/10T 000J J24205000 1- A C4
R 2075 CHIP RES. 0 1/10W 5% RMC1/10T 000J J24205000 1- A B3
R 2076 CHIP RES. 0 1/10W 5% RMC1/10T 000J J24205000 1- A C2
R 2077 CHIP RES. 560 1/10W 5% RMC1/10T 561J J24205561 1- A F7
RL2001 RELAY DC12V ACP331 DC12V M1190175 1- A H1
RL2002 RELAY DC12V G5V-1 DC12V M1190120 1- A E6
RL2003 RELAY DC12V G5V-1 DC12V M1190120 1- A E5
RL2004 RELAY DC12V G5V-1 DC12V M1190120 1- A E5
RL2005 RELAY DC12V G5V-1 DC12V M1190120 1- A E4
RL2006 RELAY DC12V G5V-1 DC12V M1190120 1- A E3
RL2007 RELAY DC12V G5V-1 DC12V M1190120 1- A E2
RL2008 RELAY DC12V G5V-1 DC12V M1190120 1- A E1
RL2009 RELAY DC12V AG231344 DC12V M1190145 1- A C1
RL2010 RELAY DC12V G5V-1 DC12V M1190120 1- A A7
RL2011 RELAY DC12V G5V-1 DC12V M1190120 1- A A6
RL2012 RELAY DC12V G5V-1 DC12V M1190120 1- A A5
RL2013 RELAY DC12V G5V-1 DC12V M1190120 1- A A5
RL2014 RELAY DC12V G5V-1 DC12V M1190120 1- A A4
RL2015 RELAY DC12V G5V-1 DC12V M1190120 1- A A3
RL2016 RELAY DC12V G5V-1 DC12V M1190120 1- A A2
T 2001 COIL 10WIDE #223153 L0022857 1- A H6
T 2002 COIL PWR-WIDE D12A RIB10 L0022249A 1-10 A G5
T 2002 COIL PWR-WIDE D12A RIB10 L0022249B 11- A G5
T 2003 TOROIDAL COIL D12A RI16X8X8(H007) L0022745 1- A I3
T 2004 COIL PWR-WIDE D12A RIB16 L0022856 1- A G1
T 2005 COIL WIDE-TRANS. #223093 L0022792 1- A A1
TC2001 TRIMMER CAP. 20pF ECR-JA020E11X K91000228 1-65 A A2
TC2001 TRIMMER CAP. 20pF TZB4R200AA10R00 K91000217 66- A A2
TH2001 THERMISTOR 112103-2 G9090043 1- A F3
TP2020 TERMINAL TP-H MK-10160 Q5000037 1- A H1
TP2021 TERMINAL TP-H MK-10160 Q5000037 1- A H1
VR2001 POT. 1k EVN-5ESX50B13 J51811102 1-2 A I8
VR2001 POT. 2.2k EVN-5ESX50BE3 J51811222 3-64 A I8
VR2001 POT. 2.2k EVM3VSX50BE3 J51843222 65-94 A I8
VR2001 POT. 3.3k EVM3VSX50BY3 J51843332 95- A I8
VR2002 POT. 1k EVN-5ESX50B13 J51811102 1-77 A I6
VR2002 POT. 1k EVM3VSX50B13 J51843102 78- A I6
VR2003 POT. 470 EVN-5ESX50BQ2 J51811471 1-68 A J6
VR2003 POT. 470 EVM3VSX50BQ2 J51843471 69- A J6
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.REF. LOT. SIDE LAY ADR
