85VX-1700 Series (EXP Version) Service Manual
MAIN Unit
Parts List
R 1344 CHIP RES. 1 1W 5% RMC1 1R0JTE J24305010 1- A B6
R 1346 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1- A J4
R 1347 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1- A B2
R 1352 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 1- A C2
R 1353 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1- A B2
R 1354 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1- A E3
R 1355 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1- A E3
R 1356 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 1- A E3
R 1357 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 1- A E3
R 1358 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 1- A E4
R 1359 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A E4
R 1360 CHIP RES. 220 1/16W 5% RMC1/16 221JATP J24185221 1- A H4
R 1361 CHIP RES. 100 1/16W 5% RMC1/16 101JATP J24185101 1-2 A C3
R 1361 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 3- A C3
R 1362 CHIP RES. 4.7k 1/16W 5% RMC1/16 472JATP J24185472 1- A B2
R 1364 CHIP RES. 470 1/16W 5% RMC1/16 471JATP J24185471 1- A C7
R 1365 CHIP RES. 470 1/16W 5% RMC1/16 471JATP J24185471 1- A D7
R 1366 CHIP RES. 470 1/16W 5% RMC1/16 471JATP J24185471 1- A E1
R 1367 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A F7
R 1368 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A F7
R 1369 CHIP RES. 33k 1/16W 5% RMC1/16 333JATP J24185333 1- A I1
R 1370 CHIP RES. 33k 1/16W 5% RMC1/16 333JATP J24185333 1- A I1
R 1371 CHIP RES. 33k 1/16W 5% RMC1/16 333JATP J24185333 1- A G1
R 1372 CHIP RES. 33k 1/16W 5% RMC1/16 333JATP J24185333 1- A H1
R 1373 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A G1
R 1374 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A G1
R 1375 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 1- A D7
R 1376 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A H1
R 1377 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A I3
R 1378 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1- A I2
R 1379 CHIP RES. 33k 1/16W 5% RMC1/16 333JATP J24185333 1-2 A B7
R 1379 CHIP RES. 18k 1/16W 5% RMC1/16 183JATP J24185183 3- A B7
R 1380 CHIP RES. 68k 1/16W 5% RMC1/16 683JATP J24185683 1- A B7
R 1381 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1- A B7
R 1382 CHIP RES. 8.2k 1/16W 5% RMC1/16 822JATP J24185822 1- A B6
R 1383 CHIP RES. 12k 1/16W 5% RMC1/16 123JATP J24185123 1- A E7
R 1384 CHIP RES. 220 1/16W 5% RMC1/16 221JATP J24185221 1- A E7
R 1385 CHIP RES. 220 1/16W 5% RMC1/16 221JATP J24185221 1- A E7
R 1386 CHIP RES. 220 1/16W 5% RMC1/16 221JATP J24185221 1- A D7
R 1387 CHIP RES. 220 1/16W 5% RMC1/16 221JATP J24185221 1- A D7
R 1388 CHIP RES. 2.7k 1/16W 5% RMC1/16 272JATP J24185272 1-6
R 1389 CHIP RES. 4.7k 1/16W 5% RMC1/16 472JATP J24185472 1- A G7
R 1390 CHIP RES. 4.7k 1/16W 5% RMC1/16 472JATP J24185472 1- A G7
R 1391 CARBON FILM RES. 100k 1/6W 5% RD16PJ104 100K J01225104 1-6 A I1
R 1391 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 7- A I1
R 1392 CARBON FILM RES. 100k 1/6W 5% RD16PJ104 100K J01225104 1-6 A I4
R 1392 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 7- A I4
R 1393 CHIP RES. 2.2k 1/16W 5% RMC1/16 222JATP J24185222 1-2 A H6
R 1393 CHIP RES. 1.2k 1/16W 5% RMC1/16 122JATP J24185122 3- A H6
R 1395 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 13- A D2
R 1396 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 13- A D2
R 1397 CARBON FILM RES. 1k 1/6W 5% RD16PJ102 1K J01225102 26-
R 1399 CHIP RES. 0 1/8W 5% RMC1/8T 000J J24215000 26-
R 1998 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1-3
R 1999 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1-3
S 1001 DIP SWITCH SSGM140100 N7090148 1- A B2
T 1001 COIL WIDE-TRANS. 040812480 L0022904 1-44 A G1
T 1001 COIL WIDE-TRANS. 080812764 L0023036 45- A G1
T 1002 COIL WIDE-TRANS. 040812480 L0022904 1-44 A H1
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.REF. LOT. SIDE LAY ADR
