Vertex Standard VX-231 - PORTABLE RADIOS

Specications are subject to change without notice or obligation.
26
WHAT IS AN IP RATING?
Specications
VX-231 VX-350 SERIES VX-410/420 SERIES (IS)
GENERAL
Frequency Range
VHF: 134 - 174 MHz
UHF: 400 - 470 MHz, 450 - 512MHz
VHF: 134 – 174 MHz
UHF: 380 – 470 MHz, 450 – 512 MHz
VHF: 146 – 174 MHz
UHF: 450 – 490 MHz
Channels 16 16 32
Power Supply Voltage 7.4 V DC±20% 7.4 V DC±20% 7.5 V DC±20%
Channel Spacing 12.5/20/25 kHz 12.5/20/25 kHz 12.5/20/25 kHz
PLL Steps
VHF: 2.5/5/6.25 kHz
UHF: 5/6.25 kHz
VHF: 1.25 /2.5 /5 /6.25 kHz
UHF: 5 / 6.25 kHz
VHF: 2.5/6.25 kHz
UHF: 5/6.25 kHz
Battery Options
2000 mAh Li-Ion
1150 mAh Li-Ion
2000 mAh Li-Ion 1100 Ni-CD IS
Battery Life (5-5-90 duty)
with Battery Saver
FNB-V104LI: 16.5 hrs
FNB-V103LI: 9.0 hrs
FNB-V96LI: 15.5 / 15 hrs FNB-V57IS: 8.8 / 8 hrs
IP Rating IP 54 IP 55 IP 54
Operating Temperature Range –22° F to +140° F (–30° C to +60° C) –22° F to +140° F (–30° C to +60° C) –22° F to +140° F (–30° C to +60° C)
Frequency Stability ±2.5 ppm ±2.5 ppm ±2.5 ppm
RF Input-Output Impedance 50 Ohms 50 Ohms 50 Ohms
Dimension (H x W x D)
4.3 x 2.3 x 1.2 inches
(110 x 58 x 30 mm) (w/ FNB-V103LI)
4.1 x 2.3 x 1.3 inches
(105 x 58 x 33 mm) (w/FNB-96LI)
4.3 x 2.3 x 1.16 inches
(108.5 x 58 x 29 mm) (w/FNB-V57IS)
Weight (Approx.)
10.1 oz (285g)
(w/FNB-V103LI, Antenna, Clip)
10.9 oz (310 g)
(w/FNB-V96LI, ANT, clip)
12.7 oz (360 g)
(w/FNB-V57IS, ANT, Clip)
RECEIVER
Sensitivity 12 dB SINAD 0.25μV typical 0.25μV 0.25μV
AdjacentChannelSelectivity
65 / 60 dB
25 kHz / 12.5 kHz
65 / 60 dB 70/ 65 dB
Intermodulation
65 / 60 dB
25 kHz / 12.5 kHz
65 / 60 dB 70 dB
SpuriousandImageRejection 65 dB 65 dB 70 dB
Audio Output
500 mW @ 4 Ohms
5% THD
500 mW @ 4 Ohms
10% THD
500 mW @ 4 Ohms
5% THD
TRANSMITTER
Output Power 5 / 1 W 5 / 1 W 5 / 1 W
Modulation 16K0F3E, 11K0F3E 16K0F3E, 11K0F3E 16K0F3E, 11K0F3E
Conducted Spurious Emissions 65 dB below carrier 65 dB below carrier 70 dB below carrier
FM Hum and Noise 45 / 40 dB 45 / 40 dB 45 dB
Audio Distortion < 3 % @1kHz < 3 % @1kHz < 3 % @1kHz
FIRST DIGIT
LEVEL OBJECT SIZE PROTECTED AGAINST EFFECTIVE AGAINST
5 Dust Protected
Ingressofdustisnotentirelyprevented,butitmustnotenterinsufcientquantitytointerferewiththe
satisfactory operation of the equipment; complete protection against contact
6 Dust Tight No ingress of dust; complete protection against contact
SECOND DIGIT
LEVEL PROTECTED AGAINST DETAILS
3 Spraying Water Water falling as a spray at any angle up to 60° from the vertical shall have no harmful effect.
4 Splashing Water Water splashing against the enclosure from any direction shall have no harmful effect.
5 Water Jets Waterprojectedbyanozzleagainstenclosurefromanydirectionshallhavenoharmfuleffects.
6 Powerful Water Jets Waterprojectedinpowerfuljetsagainsttheenclosurefromanydirectionshallhavenoharmfuleffects.
7 Immersion Up to 1 meter
Ingress of water in harmful quantity shall not be possible when the enclosure is immersed in water
underdenedconditionsofpressureandtime(upto1mofsubmersion).
8 Immersion Beyond 1 meter
Theequipmentissuitableforcontinuousimmersioninwaterunderconditionswhichshallbespecied
by the manufacturer. NOTE: Normally, this will mean that the equipment is hermetically sealed. However,
with certain types of equipment, it can mean that water can enter but only in such a manner that
produces no harmful effects.
PORTABLE RADIOS
IngressProtectionisaclassicationratingofthedegreesofprotectionprovidedagainsttheintrusionofsolidobjects,dust,water,etc.
IP Rating: First DigitIngressProtectionisaclassicationratingofthedegreesofprotectionprovidedagainsttheintrusionofsolidobjects,dust,water,etc.
IP Rating: Second DigitIngressProtectionisaclassicationratingofthedegreesofprotectionprovidedagainsttheintrusionofsolidobjects,dust,water,etc.
