29VX-4500/-4600 Series VHF FM Transceiver Service Manual
PCB with Components CS2092701 CH:8, POW:50
CS2092702 CH:512, POW:50
CS2092703 CH:8, POW:25
CS2092704 CH:512, POW:25
Printed Circuit Board FR021500D 1-3
FR021500G 4-
TOP COVER RA123420B
PACKING PAD (COVER) RA1234300
SEMS SCREW ASM3X8NI U03308002
BIND HEAD TAPTITE-B M3X8 U24308001
BIND HEAD TAPTITE-B M3X6 U24306001
SPRING LOCK WASHER
SW2.6 U71002001
CD1001 CERAMIC DISC ECDA450C24 H7901460 B b4
CF1001 CERAMIC FILTER LTM450GW H3900573 A H4
CF1002 CERAMIC FILTER LTM450EW H3900574 A G4
CF1003 CERAMIC FILTER LTM450GW H3900573 A H4
F 1001 CHIP FUSE 1.25A FCC16 132ABTP Q0000109 A B1
F 1002 CHIP FUSE 1.25A FCC16 132ABTP Q0000109 A C5
Q 1001 IC NJM7808DL1A-TE1 G1093802 A C3
Q 1003 IC TDA1519CTH G1093778 B g3
Q 1013 IC RA60H1317M1A-101 G1094554 POW:50 A C1
Q 1013 IC RA30H1317M1-101 G1094553 POW:25 A C1
Q 1042 FET 2SK880GR(TE85R.F) G3808807G B d4
Q 1044 FET 3LN01S-TL G3070330 B g2
X 1001 XTAL 32.768kHz 4809995L18 32.768KHZ H0103407 A A4
X 1002 TCXO 16.8MHz TTS14VSB-A3 16.80MHZ H9501100 A F4
XF1001 XTAL FILTER 1D50811GQ2 50.85M H1102462 A G4
REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS.
LOT
SIDE
LAY ADR
Parts List
MAIN Unit
To Next Page
