Vertiv Liebert CW Series User Manual

REV : 4
REV DATE : 6/19
DPN003224
Page :1 /1
DOWNFLOW CW106 - CW114 W/ EC FANS & FRONT DISCHARGE
Form No.: DPN001040_REV4
CABINET DIMENSIONAL DATA
LIEBERT CW
118"
2997mm
Opening
30 3/4"
781mm
Opening
Striated area indicates the
recommended minimum
clearance to be provided
for component access.
36"
914mm
33"
838mm
35"
889mm
122"
3099mm
76"
1930mm
120"
3048mm
1 1/2"
37mm
3 1/8"
80mm
15 7/8"
403mm
TYP. (3) PLACES
30 1/8"
765mm
1 3/4"
45mm
29 7/8"
757mm
28 7/8"
732mm
1 3/4"
45mm
3 1/8"
80mm
15 7/8"
403mm
TYP. (3) PLACES
28 7/8"
732mm
29 7/8"
757mm
30 1/8"
765mm
Notes:
1. Filters are accessible from front of unit only.
2. Customer piping and wiring connections
a) Standard bottom connections require unit to
be placed on a minimum of a 9" floorstand.
b) If unit is to be placed directly on the
floor, additional unit modifications are
required to relocate customer connections.
Contact your local Liebert Sales Representative.
REAR VIEW
FRONT VIEW
TOP VIEW
AIR DISCHARGE
OPENING
AIR DISCHARGE
OPENING
AIR DISCHARGE
OPENING
AIR DISCHARGE
OPENING
AIR DISCHARGE
OPENING
AIR DISCHARGE
OPENING
RETURN AIR
OPENING
35"
889mm
67 7/8"
1725mm
35"
889mm
67 7/8"
1725mm
1 3/4"
44mm
Handle
5/16"
8mm
Bezel
Model Dry Weight lbs. (kg)
CW106 1785 (810)
CW114 1925 (873)
