- Tighten the screws and tighten to the specified
torque.
CAUTION
TO AVOID DAMAGING THE OIL SEAL, USE THE SPECIFIC
TOOL PRIOR TO POSITIONING THE FLYWHEEL COVER.
Specific tooling
020940Y Flywheel cover oil seal gasket
FLYWHEEL COVER SCREWS
POSITION SIZES TORQUE (Nm)
A M6x90 11 to 13
B M6x35 11 to 13
C M6x30 11 to 13
Flywheel and starting
Removing the starter motor
- Undo the two fixing screws and remove the start-
er motor.
Engine Vespa LX - S 125 3V ie 150 3V ie (2012)
ENG - 138

Vespa LX 2012 Specifications

General

Engine Type	Single-cylinder, 4-stroke
Displacement	124 cc
Cooling System	Air-cooled
Fuel System	Carburetor
Transmission	Automatic CVT
Fuel Tank Capacity	8.6 liters
Seat Height	785 mm
Curb Weight	114 kg
Length	1, 770 mm
Width	705 mm
Height	1, 140 mm
Max Power	10.3 hp @ 7, 750 rpm
Front Suspension	Single arm with coil spring and hydraulic shock absorber
Front Brake	200 mm
Rear Suspension	Coil spring and hydraulic shock absorber
Rear Brake	110 mm drum
