WHITE GOODS
DOUBLE DOOR – 4561
CUSTOMER
SUPPORT
DECEMBER 2014
2
CHANGING THE DOORWAY DIRECTION
7- Unscrew the stationary foot of bottom hinge
and screw to Hole-1 Unscrew the hinge pin
and screw the pin to Hole 2. (Fig-9)
Figure-6
6- Unscrew the bottom hinge fixing screws and
remove it. (Fig-6)
Figure-7
Figure-8.2
8- Unscrew the stationary foot and front wheel (Fig-8.1) and screw the right side. (Fig-8.2)
Figure-8.1
Figure-9
9- Screw the bottom hinge to the left side . (Fig-9)
Hole-1
Hole-2
To Next Page
