P a r t 4 ： I n s t a l l a t i o n S t e p s
S t e p 3 ： I n s t a l l t h e s u p p o r t f o o t a s s e m b l y a n d
t h e Y - a x i s t a n k c h a i n
If installation is difficult,
adjust the offset wheel
S t e p 2 ： I n s t a l l t h e X - a x i s a s s e m b l y
The guide rail passes through the
middle of the 3 rollers. Loosen the
distance between the upper and
lower guide wheels appropriately.
After assembly, if you
find that the four feet are
not aligned, please
slightly loosen the
screws of the support
feet. After the four feet
are aligned, tighten the
screws again.
M5X8
M5X8
M5X8
M5X8
M3X6
M5X15
M5X15
M5X25
S t e p 1 ： A s s e m b l e t h e f r a m e
M5X25
M5X25
M5X25
To Next Page
