- 4 -
PRODUCT PARAMETERS
Product Name
Rolling Walker
model
FBL427111
colour
Blue/Red
Wheel size
Front 8in/Back 8in
Load bearing capacity/lb
300
PRODUCT COMPONENTS
As shown in the figure: locate the components and screws required for the main
frame and seat plate
INSTALLATION STEPS
1. As shown in the figure: Lock the straight pipe of the seat frame onto the
elliptical pipe of the main frame with screws. Pay attention that the plastic
nut above the main frame pipe is facing outward, and use a long screw to
lock the connecting piece.
