VEVOR GL320 - Page 8

7
Expanded Diagram
No.
DESCRIPTION
No.
DESCRIPTION
No.
DESCRIPTION
No.
DESCRIPTION
1
Pressure Gauge
9
Cartridge
17
O Ring
25
Pipe
2
O Ring
10
Spring
18
Connect Pipe
26
O Ring
3
Valve Assembly
11
Drain Cap
19
Kit Clamp
Band
27
Union Adapter
1
4
O Ring
12
Manifold top
20
Nut-Spl
28
O Ring
5
Handle
13
Air Bleeder
Assy
21
O Ring RPM
Tank Clamp
29
O Ring
6
Screws
14
Cartridge
22
Location Band
30
Water Relief
Nut
7
Washer
15
Manifold Assy.
Bottom
23
Tank-Lower
Half
31
Union Adapter
2
8
Tank-Upper Half
Kit
16
Inlet
24
Nut
