Over-run
If the rope tangles or spills over the side of the drum, apply tension on the rope while pressing the UP or DOWN button in
the appropriate direction to unwind the tangle.
Actuator Malfunctions
Check for power present on the connector (CU side) when unplugged and FREE FALL or LOCK buttons are
pressed.
Check electrical connector.
Clean any salt build
up. No Power
Check reset LED button on switch. Reset if needed.
Check electrical connections.
Confirm battery power is
present. Breaker Trips
If the anchor is stuck on the bottom and you hold your finger on the UP switch, the circuit breaker will trip. Reset the circuit
breaker, drive your boat toward the anchor, and press the UP button when the rope becomes slack.
It is customery to maneuver the boat closer to the anchor when raising the anchor. Care must be taken
to NOT drag the anchor with the boat’s power. This will cause product damage or injury. Do NOT use the anchor winch to pull the
boat to the anchor position. Motor the boat toward the anchor while retrieving the anchor rope.
DRUM WINCH PARTS
If ordering a part, provide the product model as well as the part number.
PART # DESCRIPTION QTY PART # DESCRIPTION QTY
1 Spool 1 21 Bearing Cap 1
2 Frame 1 22 Screws for Bearing Cap 4
3 Gear Motor 1 24 Cotter Key 1
Washers
4 Gear Motor Mounting Screws and 4
6 Gear Motor Output Shaft Bearing 1
10 Warning Label 1
11 Output Shaft 1
12 Screw for Actuator Plate 1
13 Bushing 1
17 Set Screw 1
18 Spool Tube 1
19 Bearing for Spool Tube 1
20 Retainer Ring 1
