EPIA EN-Series Operating Guide
March 9, 2006 - 10 - Version 0.35
E. Run C.C. Winstone 2001
Measured Voltage Measured Amp. Watts
Main Board +3.3V 3.381 1.027 3.472
Main Board +5V 5.071 1.515 7.683
Main Board 5VSB 5.062 0.173 0.876
Main Board +12V 12.198 0.165 2.013
14.044
Main Board Power Consumption
F. S3 Mode
Measured Voltage Measured Amp. Watts
Main Board +3.3V 0.000 0.000 0.000
Main Board +5V 0.000 0.000 0.000
Main Board 5VSB 5.085 0.297 1.510
Main Board +12V 0.000 0.000 0.000
1.510
Main Board Power Consumption
VIA EPIA EN 15000
A. Playing DVD – Power DVD 4.0
Measured Voltage Measured Amp. Watts
Main Board +3.3V 3.377 1.061 3.583
Main Board +5V 5.059 1.930 9.764
Main Board 5VSB 5.057 0.198 1.001
Main Board +12V 12.217 0.201 2.456
16.804
Main Board Power Consumption
B. Playing MP3 – Media Player
Measured Voltage Measured Amp. Watts
Main Board +3.3V 3.377 1.062 3.586
Main Board +5V 5.053 2.220 11.218
Main Board 5VSB 5.058 0.207 1.047
Main Board +12V 12.239 0.202 2.472
18.323
Main Board Power Consumption
C. Running Network Application – Files Copy
Measured Voltage Measured Amp. Watts
Main Board +3.3V 3.382 1.022 3.456
Main Board +5V 5.067 1.518 7.692
Main Board 5VSB 5.063 0.183 0.927
Main Board +12V 12.222 0.202 2.469
14.544
Main Board Power Consumption
