EPIA EN-Series Operating Guide
March 9, 2006 - 11 - Version 0.35
D. Idle
Measured Voltage Measured Amp. Watts
Main Board +3.3V 3.385 1.037 3.510
Main Board +5V 5.074 1.278 6.485
Main Board 5VSB 5.066 0.188 0.952
Main Board +12V 12.216 0.204 2.492
13.439
Main Board Power Consumption
E. Run C.C. Winstone 2001
Measured Voltage Measured Amp. Watts
Main Board +3.3V 3.380 1.022 3.454
Main Board +5V 5.062 1.717 8.691
Main Board 5VSB 5.061 0.196 0.992
Main Board +12V 12.225 0.201 2.457
15.594
Main Board Power Consumption
F. S3 Mode
Measured Voltage Measured Amp. Watts
Main Board +3.3V 0.000 0.000 0.000
Main Board +5V 0.000 0.000 0.000
Main Board 5VSB 5.083 0.323 1.642
Main Board +12V 0.000 0.000 0.000
1.642
Main Board Power Consumption
