Installation
13
Audio Connector: AUDIO
This is an interface for connections to external audio devices.
Pin Signal Pin Signal
1 LINE IN R 2 AGND
3 LINE IN L 4 +5V
5 LINEOUT_R 6 MIC IN L
7 LINEOUT_L 8 MIC IN R
9 SURROUT R 10 SURROUT L
11 SENSE_A 12 SENSE_B
13 CEN_OUT 14 LFE_OUT
15 SSROUT_R 16 SSROUT_L
17 SPDIF_IN 18 GND
Serial Port Connector: COM Port
COM port pin header can be used to attach additional ports for serial mouse
or other serial devices.
Pin Signal Pin Signal
1 #DCDA 6 #DSRA
2 RXDA 7 #RTSA
3 TXDA 8 #CTSA
4 #DTRA 9 #RIA
5 GND 10 NC
1
2
17
18
6
1
9
5
