Chapter 2
16
Multimedia Connector
It is to connect to a multimedia daughter board for more multimedia
functions.
Pin Signal Pin Signal
1 HTVD2 2 HTVD8
3 +5V 4 HTVD7
5 +5V 6 HTVD10
7 HTVD12 8 +5V
9 HTVD14 10 HTVD6
11 CAPD13 12 HTVD4
13 CAPD12 14 HTVCLKR
15 GND 16 +5V
17 CAPD14 18 DVP1DET
19 TS1ERR 20 HTVVS
21 CAPD11 22 HTVD0
23 CAPHS1 24 HTVHS
25 #PCIRST1 26 HTVD1
27 CAPD8 28 HTVD13
29 GND 30 CAPVS1
31 CAPCLK1 32 CAPD9
33 CAPD1 34 CAPD10
35 CAPD0 36 CAPD15
37 CAPD6 38 DVP0DE
39 CAPHS 40 HTVDE
41 GND 42 HTVD15
43 SMBDT 44 HTVD3
45 SMBCK 46 HTVD11
47 HTVD5 48 CAPD2
49 HTVD9 50 GND
51 CAPD3 52 HTVCLK
53 CAPD7 54 SPDIF_OUT
55 CAPCLK 56 HTVFLD
57 CAPD4 58 SPD1
59 GND 60 SPCLK1
61 GPIO2 62 DISPCLKO1
63 CAPD5 64 DISPCLKI1
65 CAPV3 66 +3V
67 GPIO3 68 +3V
69 #SIOSMI 70 +3V
71 #LDRQ1 72 LAD2
73 LAD1 74 LAD3
75 SERIRQ 76 #LFRAME
77 GND 78 LAD0
79 SIOOSC2 80 PCLKLPC
1
2
79
80
