BIOS Setup
47
PNP/PCI CONFIGURATIONS
: Move
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
Menu Level
Select Yes if you are
using a Plug and Play
capable operating
system. Select No if
you need the BIOS to
Item Help
PNP OS Installed [No]
Reset Configuration Data [Disabled]
Resources Controlled By [Auto(ESCD)]
x IRQ Resources Press Enter
PCI/VGA Palette Snoop [Disabled]
PnP / PCI Configurations
Phoenix - AwardBIOS CMOS Setup Utility
Assign IRQ For VGA [Enabled]
Assign IRQ For USB [Enabled]
** PCI Express relative items **
Maximum ASPM supported [L0s&L1]
Maximum Payload Size [4096]
configure non-boot
devices
NOTE: This section covers some very technical items and it is
strongly recommended to leave the default settings as is unless you
are an experienced user.
PNP OS Installed
Setting Description
Yes BIOS will only initialize the PnP cards used for booting (VGA,
IDE, SCSI). The rest of the cards will be initialized by the
PnP operating system
No BIOS will initialize all the PnP cards
Reset Configuration Data
This field should usually be left “Disabled”.
Setting Description
Enabled Resets the ESCD (Extended System Configuration Data)
after exiting BIOS Setup if a newly installed PCI card or the
system configuration prevents the operating system from
loading
Disabled Default setting
