EPIA ML-Series Operating Guide
E. Run C.C. Winstone 2001
Measured Voltage Measured Amp. Watts
Main Board +3.3V 3.234 2.176 7.037
Main Board +5V 4.855 3.600 17.478
Main Board 5VSB 4.866 0.051 0.248
Main Board +12V 11.927 0.182 0.210
24.973
17.529
16.619
13.610
12.068
Main Board Power Consumption
VIA EPIA ML 5000EA
A. Playing DVD – Power DVD 4.0
Measured Voltage Measured Amp. Watts
Main Board +3.3V 3.226 2.478 7.994
Main Board +5V 4.897 1.649 8.075
Main Board 5VSB 4.837 0.057 0.276
Main Board +12V 11.840 0.100 1.184
Main Board Power Consumption
B. Playing MP3 – Media Player
Measured Voltage Measured Amp. Watts
Main Board +3.3V 3.230 2.248 7.261
Main Board +5V 4.965 1.511 7.502
Main Board 5VSB 4.913 0.074 0.364
Main Board +12V 11.935 0.125 1.492
Main Board Power Consumption
C. Running Network Application – Files Copy
Measured Voltage Measured Amp. Watts
Main Board +3.3V 3.326 2.236 7.437
Main Board +5V 5.019 0.912 4.577
Main Board 5VSB 4.935 0.063 0.311
Main Board +12V 11.900 0.108 1.285
Main Board Power Consumption
D. Idle
Measured Voltage Measured Amp. Watts
Main Board +3.3V 3.294 2.118 6.977
Main Board +5V 4.984 0.731 3.643
Main Board 5VSB 4.900 0.056 0.274
Main Board +12V 11.859 0.099 1.174
Main Board Power Consumption
January 04, 2005 - 11 - Version 1.3
