VIA Technologies VAB-820 Installation Guide

VAB
VABVAB
VAB-
--
-820 Linux EVK v
820 Linux EVK v820 Linux EVK v
820 Linux EVK v3.0.2 Image Installation Guide
3.0.2 Image Installation Guide3.0.2 Image Installation Guide
3.0.2 Image Installation Guide
3
2.
2.2.
2. Image Development
Image DevelopmentImage Development
Image Development
This section explains the setup requirements for booting from a Micro SD card.
2.1. Booting from a Micro SD Card
The via
viavia
via-
--
-image
image-
--
-gui
guigui
gui-
--
-imx6qvab820.sdcard
imx6qvab820.sdcardimx6qvab820.sdcard
imx6qvab820.sdcard image allows the board to run entirely from the
Micro SD card.
The first step is to copy this image onto a Micro SD card. Insert a card into your Linux host
machine and make sure it is not mounted. Copy the image onto the Micro SD card with the
command below, replacing <device name> with the correct value for the card, for
example “sdb”.
Important:
Important:Important:
Important: Make sure you are writing to the correct device or the host system environment
could be damaged.
$ sudo dd if=via-image-gui-imx6qvab820.sdcard of=/dev/<device name> bs=1M conv=fsync
Next, on the VAB-820, set the J11 boot select jumper to the Micro SD position shown
below.
J11 boot select jumper diagram
J11 boot select jumper diagramJ11 boot select jumper diagram
J11 boot select jumper diagram
Insert the prepared Micro SD card into the VAB-820, connect an HDMI display, and power
on the device to initiate the boot process.
When the boot process is completed, you will see the OpenEmbedded desktop.
