VIA694X System Board 15
2-3 Connectors
There are many connectors on this main board. Refer to the following pages for
details.
2-3-1 Front Panel
Front panel has connectors as ““RESET,” “EXTSMI,” “HD-LED,” “PW-BT,”
“SPEAKER,” and “PW-LED”. Please refer to details as below.
RESET
EXTSMI HD-LED
PW-BT
SPEAKER
PWR LED
