Victa TORNADO EDGER TE250 User Manual

9
ASSEMBLY PROCEDURES
Before using the Edger read the safety instructions!
To avoid damage to the Edger, do not allow string or other material to
wrap around the blade or spindle. Stop the engine, disconnect spark plug
and remove material immediately if this occurs.
Handle assembly
Bail Cable Attachment
1. Remove the bail Tag. 2. Remove bail by springing hook
inwards.
3. Slide cable eyelet over bail hook. 4. Reinsert bail in handle holes
"cable side first".
Operating the Edger
1.
2.
3.
4.
9
REMOVE BAIL
HOOKS
INWARDS
BAIL HOOK
THROUGH
EYELET
RE-INSE
CABLE SIDE
HOOK FIRST
THEN
RE-INSE
RT
OTHER HOOK
Not for
Reproduction
