ESS3/ESS4
- 6 -
SECTION 1
All of these recommended components are available together in convenient repair kits for
your ESS3 or ESS4 model Regulator:
Repair Kit Part No. Description
RK-ESS3-HP 0790-0162 ESS3 Repair Kit for Oxygen, Inert Gases, Air, CO
2
,
N
2
O, Hydrogen.
RK-ESS4-HP 0790-0163 ESS4 Repair Kit for Oxygen, Inert Gases, Air, CO
2
,
N
2
O, Hydrogen.
RK-ESS4-HP200 0790-0164 ESS4 Repair Kit - 200 PSIG Delivery Models Only -
for Oxygen, Inert Gases, Air, CO
2
, N
2
O, Hydrogen.
RK-ESS3-F 0790-0165 ESS3 Repair Kit for Acetylene, LP Gas.
RK-ESS4-F 0790-0166 ESS4 Repair Kit for Acetylene, LP Gas.
CLEANING PARTS
It is recommended to clean all metal parts for oxygen service, regardless of Regulator Model
being repaired. There are several ways to clean components for oxygen service; the
following standards are recommended reading for more detailed information on methods and
processes:
• CGA G-4.1 “Cleaning Equipment for Oxygen Service”
• ASTM G-93 “Standard Practice for Cleaning Methods and Cleanliness Levels for
Material and Equipment Used in Oxygen-Enriched Environments”
• ASTM G-127 “Standard Guide for the Selection of Cleaning Agents for Oxygen
Systems”
For metal parts, Victor brand suggests using CCI Envirospray Liquid, used per the
manufacturer's instructions, followed by a hot water rinse and thorough drying. Additional
information can be found at
http://www.ccichemical.com.
DO NOT allow non-metal parts to come in contact with cleaning solvents. Cleaning solvents
can cause non-metal parts to swell and/or crack. To clean these parts, use a non-petroleum
based mild soap solution, followed by a thorough rinsing in water. Dry parts completely prior
to reassembling.
ASSEMBLY PROCEDURES
Refer to the exploded view for reference numbers [Shown in brackets]
IMPORTANT NOTES ABOUT SEALING PIPE THREADS:
• When using Teflon® tape where noted: Apply two to three layers around the
threads, leaving the first thread clean. Insure your Teflon® tape is oxygen-
compatible.
• When using Loctite® #222 Threadlocker where noted: Apply two to three drops
to the second and third thread, leaving the first thread clean.
