Increasingintensityofawatermassagecanbeconducted
byturningtheknoboftheregulatorsintotherightwhereas
decreasingintensityofawatermassageisconductedby
turningtheknobintotheleft.
Eachofthosethreeregulators
isresponsibleforcontrolling
nozzlesections.
Regulationofintensityofwaterflowthroughthebignozzle
1
2
1.Coverplate
2.Rotationalelementofthenozzle
In order to regulate water flow element nr 1 (nozzle
cover plate) shall be turned according to the
direction of arrows.
