STEP 3: Flip the unit 180, upside down.
Put A2 into the slots of B2 and B1. (A2 Label facing the inside of the crate)
Flip unit back 180.
WARNING: When holding the crate, make sure
to hold by the handles ONLY.
STEP 5:
SPECIFICATIONS
Weight: 5 lbs (2.3 kg)
Product Size: 14" (355 mm) W x 13.25" (336mm) D x 11.75" (298mm) H
Please note: As a result of continual improvements, the design and specifications of this product are
subject to change without notice. (Records and sleeves are not included.)
1. Make sure C is pushed all the way forward
into the slots of B2, A1, & B1.
2. Push A2 back into place.
STEP 4:
1. Push A2 to the top position,
2. then slide C into bottom slots (2).
Note: Make sure the C panel with
label is facing up.
3
ASSEMBLY INSTRUCTIONS
SPECIFICATIONS
A2
A2
2
1
5
WARNINGS:
• Read, heed and follow all instructions in the manual before operating.
• Keep this manual in a safe place for future reference.
• Choose unit location carefully. Avoid placing it in direct sunlight or close to a heat Also
avoid locations subject to vibrations and excessive dust, cost or moisture.
• Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.
• This product should be moved with care to avoid damage or injury.
• Do not sit or stand on unit to avoid injury.
A1
B1B2
A1
B1B2
180
A2
2
C
1
4
Slide A2 above
the top of
the side panels.
180
A2
To Next Page
