A
S
ERIES
ViewSonic A70
• OnView
®
controls including
ViewMatch
®
All screen adjustments are made via an on-screen
menu using simple controls. ViewMatch allows the
user to adjust color temperature and individual
color intensity for screen-to-print matching.
• SuperClear
™
screen
This SuperClear screen technology delivers “power
color” images that are up to 30%
†
brighter than
conventional CRT monitors and up to 10%
†
improved color fidelity. This provides vivid, realistic
color and optimized clarity.
• Anti-static, anti-glare screen
This anti-static, anti-glare coating refracts
unwanted light away from the user while
maintaining the highest quality of the displayed
image.
• MPR-II and Energy Star
®
compliant
This monitor surpasses these strict standards for
reduced emissions, power consumption and
efficiency.
•
Fully supports the Windows
®
auto-installation
standard for easy, trouble-free configuration
and setup.
• PC and Mac
®
compatible
• Three year limited warranty
381 Brea Canyon Road, Walnut, CA 91789 • Phone (800) 888-8583 • (909) 869-7976
Fax (909) 869-7958 • Internet: www.ViewSonic.com
*Free universal Mac
®
cable adapter available.
†
Compared to conventional CRT monitors, results may vary.
††
Requires GTF (general timing format) compliant video card support.
Copyright © 1999, ViewSonic Corporation. All rights reserved. Corporate names and trademarks stated herein are the property of their respective companies.
Specifications subject to change without notice. The EPA only promotes energy efficiency and does not endorse any particular company or product.
Microsoft, Windows, Windows NT and the Windows logo are the registered trademarks of Microsoft Corporation in the United States and other countries.
VSA70-1;6/99-50-rev 1
www.ViewSonic.com
17" (16.0" VIEWABLE) COLOR MONITOR WITH SUPER FINE DOT PITCH FOR SUPERIOR IMAGES
CRT Type 17" (16.0" diagonal viewable area)
0.22mm horizontal / 0.26mm diagonal dot pitch,
90° deflection
Phosphor RGB medium-short persistence
Glass Surface Tint (TM=53%) anti-static, anti-glare screen treatment
INPUT SIGNAL Video RGB analog (0.7Vp-p, 75 ohms)
Sync H/V Separate (TTL), composite sync
Frequency F
h
:30-70kHz, F
v
:50-180Hz
COMPATIBILITY PC IBM
®
XT, AT, 386, 486, Pentium
®
, PS/2 and compatibles
(from VGA up to 1,280 x 1,024 non-interlaced)
Mac
®
* Power Mac
™
(up to 1024 x 768)
CONNECTOR Signal 15-pin mini D-sub, attached cable
Power 3-pin plug (IEC320)
POWER Voltage AC 90-132V/180-264VAC (auto switch) 50/60 (+/-3)Hz
Consumption 90W (typ)
USER CONTROLS Basic Power on/off, Key–1, Key–2, down, up
OnView
®
Contrast, brightness, H/V-position, H/V-size, pincushion,
pin-balance, degauss, trapezoid, rotation, ViewMatch
®
color, parallelogram, ViewMeter
®
, language select, recall
VIDEO INPUT Bandwidth 100MHz (typ)
MISCONVERGENCE 0.3mm (max) at center
0.4mm (max) at corner
DISPLAY AREA Factory Setting 300mm(H) x 225mm(V) (Dependent upon
Maximum Scan 325.8mm(H) x 243mm(V) signal timing used)
OPERATING Temperature 32°F to 104°F (0°C to 40°C)
CONDITION Humidity 5% to 95% (non condensing)
DIMENSIONS Physical 423mm (W) x 439mm (H) x 426mm (D)
(16.7" x 17.3" x 16.8")
WEIGHT Net 18Kg (40.8 lbs.)
OTHER DDC1 & DDC2B, GTF
REGULATIONS UL, cUL, FCC-B, DHHS, MPR-II, ISO9241-3,
DOC-B, CB, CE, EPA
POWER MANAGEMENT Meets Energy Star
®
, VESA
®
, DPMS
™
standards
WARRANTY Three year limited warranty on CRT, parts and labor
48 hour Express Exchange
®
Service option available
