ViewSonic A72f Ultimate Desktop
™
A
S
ERIES
• OnView
®
controls including
ViewMatch
®
All screen adjustments are made via an on-screen
menu using simple controls. ViewMatch allows the
user to adjust color temperature and individual
color intensity for screen-to-print matching.
• Anti-static, anti-glare screen
This screen treatment refracts unwanted light
away from the user while maintaining the
highest image quality.
• MPR-II and ENERGY STAR
®
compliant
This monitor complies with the world’s strictest
standards for low radiation, safety, ergonomics,
recycling and power conservation while saving cost
through automatic power saving modes.
•
Fully supports the Microsoft
®
Windows
®
auto-installation standard for easy,
trouble-free configuration and setup.
• PC and Mac
®
compatible
• PC '99 compliant
Compliant with Microsoft
®
hardware
guidelines for increased ease of set up
and installation.
• Base accommodates optional
ViewSonic USB Hub
381 Brea Canyon Road, Walnut, CA 91789 • Phone (800) 888-8583 • (909) 869-7976 • Fax (909) 869-7958 • Internet: www.ViewSonic.com
*Free universal Mac
®
cable adapter available. ** Only available within the United States. Copyright © 2001 ViewSonic Corporation. All rights reserved. Corporate names and trademarks stated
herein are the property of their respective companies. Specifications subject to change without notice. The EPA only promotes energy efficiency and does not endorse any particular company or
product. VSA72f_3/01_web [10015-01E 04/01]
17" (16.0" VIEWABLE) COLOR MONITOR WITH SUPER FINE DOT PITCH FOR SUPERIOR IMAGES
CRT Type 17" (16.0" diagonal viewable area)PerfectFlat
®
0.20mm horizontal / 0.25mm diagonal dot pitch,
90° deflection
Phosphor RGB medium-short persistence
Glass Surface Tint (TM=52.6%) anti-static, anti-glare screen treatment
INPUT SIGNAL
Video RGB analog (0.7Vp-p, 75 ohms)
Sync H/V Separate (TTL), composite sync
Frequency F
h
:30-70kHz, F
v
:50-180Hz
COMPATIBILITY
PC IBM
®
XT, AT, 386, 486, Pentium
®
, PS/2 and compatibles
(from VGA up to 1,280 x 1,024 non-interlaced)
Mac
®
* Power Mac
™
(up to 1152 x 870)
CONNECTOR
Signal 15-pin mini D-sub, attached cable
Power 3-pin plug (IEC320)
POWER
Voltage AC 90-132V/180-264VAC (auto switch) 50/60 (+/-3)Hz
Consumption 85W (typ)
USER CONTROLS
Basic Power on/off, Key–1, Key–2, down, up
OnView
®
Contrast, brightness, H/V-position, H/V-size, pincushion,
pin-balance, degauss, trapezoid, rotation, ViewMatch
®
color, parallelogram, tilt, corner hooking, ViewMeter
®
,
language select, recall
VIDEO INPUT Bandwidth 108MHz (typ)
MISCONVERGENCE 0.3mm (max) at center
0.4mm (max) at corner
DISPLAY AREA
Factory Setting 310mm(H) x 232mm(V) (Dependent upon
Maximum Scan 325mm(H) x 244mm(V) signal timing used)
OPERATING
Temperature 32°F to 104°F (0°C to 40°C)
CONDITION Humidity 5% to 95% (non condensing)
DIMENSIONS
Physical 408mm (W) x 428mm (H) x 420mm (D)
(16.1" x 16.8" x 16.5")
WEIGHT Net 16.5Kg (36.4 lbs.)
OTHER DDC1 & DDC2B, GTF
REGULATIONS UL, cUL, FCC-B, DHHS, MPR-II, DOC-B, CB,
CE, EPA, Energy 2000
POWER MANAGEMENT Meets ENERGY STAR
®
, VESA
®
DPMS standards
WARRANTY Three-year limited warranty on CRT, parts and labor.
48-hour Express Exchange
®
Service option available
**
,
ViewSonic Corporation’s QMS/EMS has been registered to ISO 9001
and ISO 14001 by the British Standards Institution
Ultimate Desktop™ Wireless Keyboard and Mouse sold separately
