• 0.25mm aperture grille
This super fine aperture grille pitch
produces clear, crisp images with rich vivid
colors, even at the highest resolutions.
• OnView
®
Controls
including ViewMatch
®
All screen adjustments are made via an
on-screen menu using simple controls.
ViewMatch allows the user to adjust color
temperature and individual color intensity
for screen-to-print matching.
• ARAG
®
Screen Treatment
This specially formulated anti-reflection,
anti-glare screen uses a multi-layer process
to refract unwanted light away from the
user while maintaining the highest quality
of the displayed image.
• MPR-II and EPA Energy Star
®
compliant
This monitor surpasses these strict
standards for reduced emissions, power
consumptions and efficiency.
•
Fully supports the Windows
®
95
auto-installation standard for easy,
trouble-free configuration and setup.
• PC and Mac
®
compatible
A
S
ERIES
ViewSonic A75f
381 Brea Canyon Road, Walnut, CA 91789 • Phone (800) 888-8583
• (909) 869-7976 Fax (909) 869-7958 • Internet: www.ViewSonic.com
*Free universal Mac
®
cable adapter available.
†
Compared to conventional CRT monitors, results may vary.Copyright ©
1999, ViewSonic Corporation. All rights reserved. Corporate names and trademarks stated herein are the property of their
respective companies. Specifications subject to change without notice. The EPA only promotes energy efficiency and does
not endorse any particular company or product.Microsoft, Windows, Windows NT and the Windows logo are the
registered trademarks of Microsoft Corporation in the United States and other countries.
VSA50-2;6/99-50-rev2
www.ViewSonic.com
17" (16.0 " VIEWABLE) SUPERIOR VALUE FOR PERSONAL COMPUTING
CRT Type 17" (16.0" diagonal viewable area)
0.25mm aperture grille, 90° deflection
Phosphor RGB B22 medium-short persistence
Glass Surface Anti-reflection and anti-static, TM = 41.5%
INPUT SIGNAL Video RGB analog (0.7Vp-p, 75 ohms)
Sync H/V Separate (TTL)
Frequency F
h
:30-70kHz, F
v
:50-160Hz
COMPATIBILITY PC PC compatible from VGA up to 1280 x 1024
Mac
®
*
Power Mac
™
/G3
™
(*Requires Mac cable adapter.)
CONNECTOR Signal 15-pin mini D-sub, (attached cable)
Power 3-pin plug (IEC320)
POWER Voltage AC 90-132/180-264 VAC (auto switch) 50/60 (+/-3) Hz
Consumption 95W (typ.), 110 W (max.)
USER CONTROLS Basic 1, Down, Up, 2, Power
OnView Contrast, brightness, H/V-size, H/V-position, pincushion,
trapezoid, parallelogram, V Linearity Center/Symmetry,
Tilt, H/V Moire Reduction, Degauss, ViewMeter, ViewMatch
Color (9300K, 6500K, 5000K, User), H/V OSD Position,
Language (Eng., Fre., Ger., Ita., Spa.), Memory Recall
VIDEO INPUT Bandwidth 110MHz
MISCONVERGENCE 0.25mm (max.) at center
0.35mm (max.) at corner of Standard Display Area
DISPLAY AREA Factory Setting 300mm (H) x 225mm (V) (Standard Display Area)
Maximum Scan 325mm (H) x 243mm (V) (Dependent upon
signal timing used)
OPERATING Temperature 32°F to 104°F (0°C to 40°C)
CONDITION Humidity 5% to 95% (non condensation)
DIMENSIONS Physical 417mm (W) x 427.5mm (D) x 425mm (H)
(16.4" x 16.8" x 16.7")
WEIGHT Net 20.0 Kgs (44.1 lbs.)
OTHER DDC1 & DDC2B
REGULATIONS UL, CSA, FCC-B, CB, ISO9241-3,
CE, DHHS, DOC-B, MPRII, EPA
POWER MANAGEMENT Meets DPMS, Engery Star, Energy 2000 and VESA standards
WARRANTY Three year limited warranty on CRT, parts and labor
48 hour Express Exchange
®
Service option available
ViewSonic Corporation’s QMS/EMS has been registered to ISO 9001
and ISO 14001 by the British Standards Institution
