7
ViewSonic Corporation Confidential - Do Not Copy VG2030wm-1
29 1280 x 720 @ 50 Hz, 37.5 KHz
30 1280 x 720 @ 60 Hz, 45 KHz
31
1280 x 768 @ 50 Hz, 39.6 KHz
For SOG sync, the Information OSD will be
1024x768@50Hz, the OSD content also can be changed
to 1280x768@50Hz by [1]+[2] short cut key.
32
1280 x 768 @ 60 Hz, 47.8 KHz
For SOG sync, the Information OSD will be
1024x768@60Hz, the OSD content also can be changed
to 1280x768@60Hz by [1]+[2] short cut key.
33
1280 x 768 @ 75 Hz, 60.3 KHz
For SOG sync, the Information OSD will be
1024x768@75Hz, the OSD content also can be changed
to 1280x768@75Hz by [1]+[2] short cut key.
34 1280 x 960 @ 50 Hz, 49.4 KHz
35 1280 x 960 @ 60 Hz, 59.7 KHz
36 1280 x 960 @ 75 Hz, 75.2 KHz
37 1280 x 1024 @ 60 Hz, 64 KHz
38 1280 x 1024 @ 75 Hz, 80 KHz
39
1400 x 1050 @ 60 Hz, 65.3 KHz
For Analog sync, switch 1680x1050@60Hz and
1400x1050@60Hz by [1]+[2] short cut key
(primary=1680x1050@60Hz)
40 1440 x 900 @ 60 Hz, 55.5 KHz
41 1440 x 900 @ 75 Hz, 75 KHz
42 1600 x 1200 @ 60 Hz, 75 KHz
43
1680 x 1050 @ 60 Hz, 64.7 KHz
For Analog sync, switch 1680x1050@60Hz and
1400x1050@60Hz by [1]+[2] short cut key
(primary=1680x1050@60Hz)
*1. Tolerance ±2KHz.≧
*2. Any timing not in the list, it should display as normal or show on “OUT OF RANGE” OSD message without blanking.
*3. The image quality of 85Hz mode might be worse than 75Hz.
7 AUDIO INTERFACE (SPEAKER SPECIFICATION)
SPEAKER SPECIFICATION
LINE INPUT CONNECTION 3.5 MM STEREO JACK
LINE INPUT SIGNAL 1.0 VRMS
LINE INPUT IMPEDANCE 10 KOHM
MAXIMUM POWER OUTPUT (ELECTRIC) 2 W / CH
SIGNAL TO NOISE RATIO 50 DB
FREQUENCY RESPONSE 100 HZ – 20 KHZ
DISTORTION < 10 % THD (@1KHZ)
VIBRATION
THERE SHOULD BE NO AUDIBLE VIBRATION
WITH VOLUME AT 100% AND TREBLE / BASS
AT DEFAULT.
SCREEN IMAGE
THERE SHOULD BE NO AFFECT ON THE
SCREEN IMAGE STABILITY UNDER ANY
CONDITIONS.
CONNECTOR PC99 REQUIREMENT AUDIO IN LIME GREEN PANTONE # 577C
CABLE TYPE / LENGTH 3.5MM STEREO CABLE / 1.8M LENGTH
AUDIO DPMS
SPEAKERS SHOULD BE OFF WHEN THE REST
OF THE MONITOR IS IN POWER SAVING.
* No any sympathetic or abnormal noise allowed.
