60
ViewSonic Corporation Confidential - Do Not Copy VG2030wm-1
ViewSonic Model Number: VS11425
Rev: 1a
Serial No. Prefix: QCC
Item ViewSonic P/N Ref. P/N Description Q'ty
1 N/A 2024274401P FRONT BEZEL (VG2030WM) ABS HB PS-7604B/BLACK C 1
2 N/A 2044269001P FUNCTION KEY (VG2030WM) POWER KEY ABS HB AL-PLATE 1
3 N/A 2053756301P LED INDIC.-PWR VG2030WM/PMMA 1
4 N/A 2044270701P FUNCTION KEY (VG2030WM) ABS HB AL-PLATE 1
5 M-SCW-0824-0812 2084730062P SCREW,BND T+ M3X6(BND T+) 2
6 M-SCW-0824-0812 2084730062P SCREW,BND T+ M3X6(BND T+) 2
7 N/A 2084740082P SCREW,BND T+ M4X8(BND T+) 4
8 N/A 2071983000P METAL FITTG (FOR AUO PANEL) VG2030WM-DUAL/SECC T=0.8mm 1
9 N/A 2080005100P SCREW,SPE M3*6 CANERA SCREW BLACK NY10K 4
10 M-SCW-0824-0812 2084730062P SCREW,BND T+ M3X6(BND T+) 6
11 M-SCW-0824-0811 2080003700P SCREW,SPE ISZZTER001A M3*6L MSWR17/FZMYI 2
12 M-SCW-0824-0811 2080003700P SCREW,SPE ISZZTER001A M3*6L MSWR17/FZMYI 3
13 N/A 2071678600P SHIELD PLATE VG2030WM-DUAL/SPTE T=0.3mm 1
14 N/A 2082630042P SCREW M3*4 P=0.5 5
15 N/A 2071884600P BRACKET,FIX VG2030WM HINGE FIX SECC T=1MM 1
16 N/A 2084740082P SCREW,BND T+ M4X8(BND T+) 2
17 N/A 2022269801P CABI BACK (VG2030WM-DUAL) ABS HB BLACK C 1
18 HW-00003031 2071872900P BRACKET,FIX JT198QP SECC 0.8T WALL MOUNT 1
19 N/A 2082630064P SCREW M3*6 P=0.5 BLACK 4
20 M-BK-0805-0070 2071869400P BRACKET,FIX METAL PLATE 1.0MM KENSINGTON 1
21 PL-00008058 2028050300P STAND CJC STAND ASS'Y BLACK C 1
22 M-SCW-0824-6746 2087340126P SCREW,B SPW+ 4X12(+)SWRM-3 ZMC2-C 4
23 N/A 2027264401P DUST COVER (VG2030WM) CJC HINGE COVE ABS HB BLACK C 1
24 N/A 2427404027P WIRE HARNESS 2+2/4P H/H 1061#24 L=370mm 1
25 N/A 2427410009P WIRE HARNESS 4+6/10P H/H 1007#26 L=385/330 1
26 N/A 2427409007P WIRE HARNESS 9/9P H/B 1007#26 L=150mm 1
27 N/A 2420330161P FFC CABLE 30P*P0.5mm*L126mm 1
28 E-00008186 2391302008P SPEAKER ASS'Y 2W/4ohm (L) D.L 1
29 E-00008185 2391302007P SPEAKER ASS'Y 2W/4ohm (R) D.L 1
EXPLODED PARTS LIST ( VG2030wm-1)
