Illustration symbols
This symbol serves to link
the Figs. on the illustration
pages with the
corresponding text
passages in the
instruction manual.
The figures can be found at the
front of the instruction manual.
Designation of text passages
The operating steps described
may be designated in different
ways.
Operating step with direct
reference to the relevant figure
to be found in the illustration
pages (at the front of the
instruction manual), with a
corresponding reference to the
item number in the figure.
Example:
• Release bolt (1), operate
lever (2) ...
In addition to descriptions of
operating steps, this instruction
manual includes text passages
containing important additional
information. Such passages
are identified using the symbols
described below in order to
especially emphasise them in
the instruction manual:
General lists, which do not
refer to the illustrations.
Example:
- use of the product for
sporting or competitive
events
Danger of accident and
risk of injury to persons
and serious damage to
property.
Information for better use
of the appliance and in
order to avoid possible
operating errors, which
may result in damage to
the appliance or to the
individual components.
Viewing direction when “left“
and “right“ is used in the
instruction manual:
the user is standing behind the
appliance (working position)
and is looking forwards in the
direction of travel.
A Upper handlebar
B Starter cable
C Rotary handle
D Cable clip
E Identification plate with
serial number
F Housing
G Carrying handle
H Engine
I Ejection flap
J Motorstop lever
K Working depth rotary
handle
L Scarifying unit lever
Observe the operating and
maintenance instructions
contained in the separate
engine instruction manual.
Ensure that you are familiar
with the controls and use of
the appliance.
Before initial use, advice
should be obtained from the
vendor or another expert.
The lawn scarifier should not
be operated after the
consumption of alcohol,
medications which impair
reactions, or drugs.
This appliance is not suitable
for use by persons (including
children) with impaired physical,
sensory or mental faculties or
those lacking the appropriate
experience and/or knowledge,
unless supervised by a person
responsible for their safety or
having received instructions on
use of the appliance from such
person.
Children must be supervised, in
order to ensure that they do not
play with the appliance.
1
02. Notes on the
instruction manual 03. Appliance overview
1
04.01 General
These safety
regulations must be
observed when
working with the lawn
scarifier.
Read the whole
instruction manual
before using the
appliance for the first
time and keep in a
safe place for future
reference.
