0478 670 9903 A - EN
8
Loosen the rotary handles (3)
until they can be moved easily
backwards and forwards in the
machined grooves.
Fold down the upper handle -
bar and rest it on the
appliance.
Folding down the handlebar:
Fold down the handlebar for
cleaning the mower, for space-
saving transport and for
storage of the appliance:
The machined grooves in
the threads of the flat head
bolts prevent the rotary
handles from becoming
completely detached from
the bolts (safeguard
against loss).
NOTE
Risk of injury!
The engine must be
switched off and the spark
plug socket disconnected
prior to folding down the
handlebar. No loads must
be placed on the upper
handlebar (e.g. hanging
work clothing over the
handlebar).
Danger of pinching!
The handlebar can be folded
down by releasing the rotary
knobs. For this reason,
always hold the upper
handlebar (A) with one hand
at its highest point when you
unscrew the rotary knobs.
WARNING
The cable holder 8) can be
individually adjusted along
the handlebar (Torx 25
screwdriver not included in
standard equipment).
NOTE
Detach spark plug socket from
the engine.
Slowly pull out the starter
cable (B) and attach to the
cable guide (8) as shown in
the illustration.
Connect spark plug socket.
07.02 Attaching the
starter cable
4
6 different working depths can
be set.
Level 1: Shallowest working
depth
Level 6: Deepest working
depth
The adjustment range is
25 mm.
Step :
Bring the scarifying unit
lever (L) into position .
(Transport position
a Raising the scarifying
unit”)
Step :
Set the required working
depth via the working depth
rotary handle (K).
07.03 Adjusting the
working depth
5
Fit upper handlebar (A) onto
both parts of lower
handlebar.
Push flat head bolts (2) with
cable guide through bores
from the inside towards the
outside and fasten securely
using rotary handles (3).
Attach cable (6) at right anti-
kink protection as illustrated.
Attach cable (7) at left anti-
kink protection as illustrated.
Secure the cable to the
lower handlebar and upper
handlebar using two cable
clips (4) as illustrated.
Ensure a distance of
25 - 27 cm between the
cable clip and housing on
the upper handlebar.
07.01 Assembling the
handlebar
3
