Viking RAD-1 - RAD-1 Programming Procedures; Setting the Security Code

Note: For this application, JP1 on the DVA-2WA must be removed.
Installation and programming specifications for the DVA-2WA are available in
the DVA-2WA Technical Practice, Fax Back Document 110.
VIKING
©
MODEL RAD-1
VIKING
ELECTRONICS
HUDSON, WI 54016
REMOTE ACCESS DEVICE
LINE
IN
LINE
OUT
C.O. Line
Analog
PABX/KSU
Stations
600Ω : 600Ω
1 2 3 4 5
WATS, FX
or TIE line
MODEL SO-24A
VIKING©
24 LINE
SERVICE OBSERVING UNIT
VIKING
ELECTRONICS
HUDSON, WI 54016
POWER
13.8 VAC
STATUS LED
1 2 3
OFF
MASTER
PROGRAM
RECORD CONTROL
RJ21X
LINE / STATION CONNECTIONS
TAPE RECORDER
CONNECTIONS
MULTI-UNIT
COMMUNICATIONS
ON
OFF
INPUT OUTPUT
RECORD
CONTROL
OUT
AUDIO
OUT
PABX/KSU
Model SO-24A
The RAD-1 can be used to access the SO-24A Service Observing unit. Note: For two-way voice applications a deci-
bel loss may occur. In this case, the RAD-AMP is recommended.
D. Remote Service Observation
P
P
r
r
o
o
g
g
r
r
a
a
m
m
m
m
i
i
n
n
g
g
A. Security Code
3.
?
Need More Information on the RAD-AMP?
Call (715) 386-4345 and select 415.
?
Need More Information on the SO-24A?
Call (715) 386-4345 and select 690.
E. Single Line 7.5 Minute Digital Announcer
The security code allows the user/installer to program the RAD-1. The factory preset security code is 845464 (V-I-K-
I-N-G). To program your personal security code follow the directions below.
Important: It is recommended that the factory set security code be changed. This number should be written down
and stored in a safe place.
Note: While programming, if no Touch Tones are entered for 20 seconds, the RAD-1 will disconnect.
Step 1. Call into the RAD-1.
Step 2. Dial ✱ followed by 845464 (a double beep should be heard).
Step 3. Enter your new 6 digit security code followed by #47 (a double beep should be heard).
VIKING
©
MODEL RAD-1
VIKING
ELECTRONICS
HUDSON, WI 54016
REMOTE ACCESS DEVICE
LINE
IN
LINE
OUT
C.O. Line or Analog
PABX/KSU Station
600Ω : 600Ω
1 2 3 4 5
Model DVA-2WA
(not included)
VIKING
©
MODEL DVA-2WA
VIKING
ELECTRONICS
HUDSON, WI 54016
DIGITAL ANNOUNCER
WITH 2 WATT AMPLIFIER
POWER 12V DC
STATUS LED
AUX. AUDIO INPUT/MOH RECORD AUDIO INPUT (MIC/TAPE) HANDSET REC/MONITOR
DEFAULT MSG. MESSAGE REPEAT DELAY TIMES
1234
REMOTE TRIGGER (STRAP TO REPEAT)
12
SPEAKER OUTPUT
34
600 OHM AUDIO OUTPUT
MASTER
VOLUME
AUX. AUDIO
VOLUME
START/STOP
MIN MAX
MIN MAX
Remove
JP1
?
Need More Information on the DVA-2WA?
Call (715) 386-4345 and select 110.
In this application, the RAD-1 will answer the line and trigger the message on the DVA-2WA to play from the begin-
ning. The RAD-1 Call Timer must be programmed to a time long enough for the DVA-2WA to play its entire message
(see Programming section B).
