6.
Due to the dynamic nature of the product design, the information contained in this document is subject to change without notice. Viking Electronics, and its affiliates and/or
subsidiaries assume no responsibility for errors and omissions contained in this information. Revisions of this document or new editions of it may be issued to incorporate
such changes.
Fax Back Doc 410
ZF300330 Rev D
Printed in the U.S.A.
P
P
r
r
o
o
d
d
u
u
c
c
t
t
S
S
u
u
p
p
p
p
o
o
r
r
t
t
L
L
i
i
n
n
e
e
.
.
.
.
.
.
7
7
1
1
5
5
.
.
3
3
8
8
6
6
.
.
8
8
6
6
6
6
6
6
F
F
a
a
x
x
B
B
a
a
c
c
k
k
L
L
i
i
n
n
e
e
.
.
.
.
.
.
7
7
1
1
5
5
.
.
3
3
8
8
6
6
.
.
4
4
3
3
4
4
5
5
When the LINE OUT relay has been actuated, several other commands can be used. For a 500ms hookswitch flash on the
LINE OUT port, dial #1. To create a 2 second disconnect on the LINE OUT port for making a new call, dial #2. To discon-
nect the RAD-1, dial #7. The RAD-1 will also disconnect when a CPC break occurs on the LINE IN port or after the call
timer has expired. When disconnecting, both LINE IN and LINE OUT relays are opened.
The SO-24A mode is useful when using the RAD-1 with other devices that use Touch Tone commands in their operation,
such as the Viking’s SO-24A. In this mode, the RAD-1 will only accept the #7 hang-up command. All toll restriction func-
tions are disabled.
Note: For applications where an audio decibel loss is a problem, the RAD-AMP is suggested.
?
Need More Information on the SO-24A?
Call (715) 386-4345 and select 690.
O
O
t
t
h
h
e
e
r
r
P
P
r
r
o
o
d
d
u
u
c
c
t
t
s
s
SO-24A Service Observation Unit
The SO-24A allows supervisors to silently monitor employee phones without disrupting
the activity at their workstation. The information gathered may be used for quality pur-
poses, to train, motivate even assist customer service and telemarketing representatives.
A supervisor may enter the conversation by dialing a “
✱.” A cassette recorder output per-
mits automatic or manual recording of conversations.
The SO-24A features improved audio and can now be easily expanded to 240 stations
by installing additional SO-24A’s. The SO-24A can be programmed with a 2, 3 or 4 digit
dial up code to match station extension numbers.
DVA-2WA Digital Voice Announcer with Amplifier
PA-2A Paging/Loud Ringing Amplifier System
The PA-2A provides loud ringing and paging to electronic key systems, 1A2 Key sys-
tems, PABX’s as well as No-KSU phones and multiline phones.
Paging is accomplished by connecting the PA-2A to a paging port or unused C.O.
line input of nearly any phone system. The PA-2A will also generate an adjustable
loud warble from up to 6 C.O. lines or from a dry contact closure. An external “night
transfer” switch can be added to turn loud ringing on or off in night bell applications.
The PA-2A is easy to install and eliminates the installation of multiple bells, relays
and paging cards. The unit comes complete with a power supply, amplifier and (1)
paging horn.
?
Need More Information on the SO-24A?
Call (715) 386-4345 and select 690.
?
Need More Information on the DVA-2WA?
Call (715) 386-4345 and select 110.
?
Need More Information on the PA-2A?
Call (715) 386-4345 and select 485.
The DVA-2WA is a digital announcer with a built in 2 watt amplifier. Designed to
provide music and promotion on hold, the DVA-2WA can playback in a continuous
loop or alternate between promotions and an auxiliary music source in timed inter-
vals. Any number of multiple messages may be recorded. The announcer comes
with four professionally pre-recorded promotion on hold messages, a power supply
and cabling for an easy plug and play installation.
The output of the DVA-2WA may also be connected directly to loudspeakers for
repeated messages or played at the push of a button for museum displays, infor-
mation booths, point of interest locations, retail applications, etc.
The DVA-2WA’s non-volatile memory eliminates the need for batteries or costly built
in tape decks. This provides the convenience of recording at the shop or profes-
sional studio and then shipping to the installation site.
