17
POLE SAW & HEDGE TRIMMER
Prior To Assembly
Unerstanding your machine helps The terms “left-hand”, and “LH’
ensure top performance, longer service ‘right”, ”right-hand”, and”RH’, ”front”
life, and safer operation. And”rear”refer to directions as viewed
Before assembling, make sure you by the operator during normal
have all the components required for operation.
a complete unit:
■ Powerhead assembly
■ Lower tube assembly
■Upper tube/saw assembly, chain
and guide bar
■ Kit with this manual and tool kit
for routine maintenance.
■ Chain cover.
Installing and Adjusting the Bar and Chain
WARNING
Do not make unauthorized
modification or alterations to
your pruner or its components
WARNING
Never attempt to install, replace or
adjust the chain with engine running.
WARNING
The saw chain is very sharp. Wear
gloves to protect your hands when
handling.
