Vimar ELVOX SW24.W User Manual

22
SW24.W
LGC
L5
Apartment block (OFF)
Apartment block function o󰀨 OFF
Does not close and stop in open-
ing
1
Does not close and stop in open-
ing and pause
2
Does not close and stop in open-
ing, pause and closing
3
L6
Rapid closing (OFF)
Rapid closing function o󰀨 OFF
Rapid closing in gate mode:
The control panel starts to count
the clearance time (L7) from when
the closing photocell is released,
when the clearance time expires it
closes again.
1
Rapid closing in barrier mode:
The control panel starts to count
the clearance time (L7) from
when the closing photocell is
released, and when the clearance
time expires it closes again. If
the closing photocell is occupied
again, it gives a stop command.
When released again it continues
with closing. The closing photocell
returns to normal operating after
complete closure.
2
L7
Clearance time (adjustable at
intervals of 1 s)
Time after which the gate closes
again if the rapid closing (L6) is on
(2)
Minimum clearance time 1
Maximum clearance time 10
L8
Pre-ash
Flashing time of the ashing light
before the gate starts to move
(OFF)
Pre-ash disabled OFF
3 s pre-ash 3
4 s pre-ash 4
5 s pre-ash 5
L9
Manned (OFF)
Manned function o󰀨 OFF
Step-step command disabled,
remote controls not working. The
control panel accepts only open
and close commands
1
Emergency manned. In normal
standard operating conditions, with
the safety devices occupied it
works as manned.
2
LGC
L10
Step by step (4)
Step-step command operates in
2 steps:
open, close, open...
2
Step-step command operates in
3 steps:
open, stop, close, open...
3
Step-step command operates in
4 steps:
open, stop, close, stop, open...
4
L11
Stop from step-step (ON)
Automatic closing disabled when a
stop command from step-step
is given
OFF
Automatic closing not disabled
when a stop command from step-
step is given
ON
L12
Stop from stop (ON)
Automatic closing disabled when a
stop command from stop is given
OFF
Automatic closing not disabled
when a stop command from stop
is given
ON
L13
Hammering
Moves briey in the opposite direc-
tion to that of its travel to facilitate
the release of the electrical lock
(OFF)
Hammering o󰀨 OFF
On with gate closed 1
On with gate closed and open 2
On with gate open 3
L14
Operation in battery (1)
Standard operation 1
Normal operation with ashing light
disabled
2
After a re-open command it stays
open
3
When the main power supply is cut
o󰀨 it opens and remains open
4
L15
Economy (OFF)
Standard operation OFF
Economy operation on. With the
gate closed, it switches o󰀨 the ac-
cessory power supply on outputs 1
and 2. The outputs are powered
again following a new command.
1
L16
Gate remained open indica-
tor Number of minutes after
which, with the gate partially or
totally open, whatever the set
pause time, an alarm signal is
sent (on the display and output
congured
as OAB)
(30)
Indicator disabled OFF
Minimum interval 3
Maximum interval 60
EN
