LIGHTING OPTIONS
Three Options to Combined
The QT cabinet features three LED lighting options, all of which can be combined in one cabinet for a better
display.
The lighting options are:
LED Light Bar
– Light Bar at the top of the cabinet.
LED Display Row
–Lighting across the Display Row.
LED Perimeter
–Perimeter lighting along the glass on the cabinet door(s).
Note: If the cabinet only brings one lighting option then it will be controlled by a switch on the controller
box. When two or three lighting options are purchased with the cabinet it comes with a remote that enables
the user to turn on each option individually. The remote is able to control the power on up to three lighting
options, as shown in the diagram below.
Controls Light Option 1
Controls Light Option 2
Controls Light Option 3
ON
I
II
III
I
II
III
OFF
