6.3 Unscrew drag knob boss (4) and remove two shim washers (5) and eight disc springs (6). Note
arrangement of disc springs and shim washers for re-assembly.
6.4 Remove grommet (8) complete with drag detent ring (7).
6.5 Referring to Fig 6.4, remove four screws (15), which are secured with Loctite.
6.6 Prise off tilt brake knob cap (19) and remove the old adhesive from the knob and cap.
6.7 Release the tilt brake. Remove screw (18) and tilt brake knob (17). Unscrew and remove tilt
brake shaft (22) complete with tilt brake insert (23).
6.8 Turn outrigger (14) clockwise relative to tilt housing (1) until the tilt brake boss lies on an
imaginary line from the tilt drag boss to the centre of the pan bar mounting.
6.9 Apply masking tape or similar padding to the faces and tips of two large flat-bladed screwdrivers
and insert them in the gap between the outrigger and the tilt drag housing. Taking care to avoid damage
to the surface finishes, draw the outrigger off two Spirol pins (25) in the tilt drag shaft.
6.10 Remove Spirol pin (31) from tilt drag actuator shaft (2).
6.11 Support the constant drag assembly (8) with inboard end of tilt drag shaft (26) upwards, ensuring
that supports are clear of tilt brake disc (11).
6.12 Loosen two screws (13).
6.13 Remove six screws (9). Using a soft-faced mallet, gently tap the constant drag assembly (8) until
it may be removed. Drive out Spirol pin (6).
6.14 Remove two screws (13). gently tap the tilt drag shaft (26) to remove the labyrinth assembly (7),
spacer (28) and shim pack (29). Retain the shim pack (29) for reassembly. Ensure that the surfaces of
the friction rings on the labyrinth are not damaged or contaminated.
6.15 If access is required to bearing (27) remove six screws (24), which are secured with Loctite, and
two Spirol pins (10) to release tilt brake clamp (12) and give access to bearing (27).
6.16 If access is required to tilt drag thrust bearing (4), remove six screws (30) and drive out two Spirol
pins (6) which secure friction plate (5) in tilt drag housing (1).
6.17 Lift out tilt drag actuator shaft (2) complete with friction plate (5), thrust bearing (4) and thrust
washer (3).
WARNING!: The outrigger must be turned so that the cast features in the outrigger are
aligned with the cutout in the brake disc.
