Viper AS380/15C-EU User Manual

USER MANUAL
9
Control panel
47. Control panel
48. Brush motor switch
49. Vacuum motor switch
50. Solution switch
TECHINICAL DATA
Machine length*width*height 770x500x550MM
Solution tank capacity 15L
Recovery tank capacity 15L
Wheel diameter 254MM
Brush motor data 220V-240V 250W
Vacuum motor data 220V-240V 300W
Electromagnetic valve data 220V-240V
Maximum gradient 2%
Sound level 72 dBA
Power cable length 15M
Working capacity, up to 800mm H
2
O
Cleaning productivity 750m
2
/hour
Squeegee width 490mm
Brush diameter 380mm
Brush rpm 140rpm
Charger /
Machine weight 39kg
Machine weight(with charger and package) 44kg
Carton spec 780x415x590MM
