YOKO | User’s Manual
5. YOKO CONFIGURATION
ON X-PLANE 10
• Execute “X-PLANE”. Once loaded, if a plane select screen appear, pro-
ceed loading a flight.
• Move your mouse to the top of the screen, causing the menu to ap-
pear. It has some options as: About, File, Aircraft, location, environ-
ment, settings… Click on “Settings” and in the dropdown list click on
“Joystick & equipment”.
Axes assignment
• In the dialog box that appears, choose the “Axis” tab.
• Move the YOKO to the left and to the right. A green or red bar should
move as you do. Click the drop-down menu next to it and set it to “Roll”.
• Repeat the above steps in order to set “pitch”.
Buttons assignment
• Choose the “Buttons Basic” tab of “Joystick & equipment”.
• Press a button or switch of YOKO. (You will see in the top and left part
of the screen a text box with three values which change according to
the button you press).
• Then, click the function you want that button perform.
• Repeat the steps above for each button you want to assign.
• A recommended conguration would be:
• Left control yoke switch (backward): “Pitch trim up”.
• Left control yoke switch (forward): “Pitch trim down”.
• Right control yoke switch (to the left): “Rudder trim left”.
• Right control yoke switch (to the right): “Rudder trim right”.
Sensitivity adjustment
• Choose the “Null zone” tab of “Joystick & equipment”.
• To adjust the sensitivity of the pitch axis move the slider: “Pitch control-
response”. Moving to the right increase sensitivity and vice versa.
• To adjust the sensitivity of the roll axis move the slider: “Roll control-
response”. Moving to the right increase sensitivity and vice versa.
