# PART CODE DESCRIPTION QTY
1 VF93010 Horizontal Beam 1 4
2 VF93011 Horizontal Beam 2 2
3 VF93010 Horizontal Beam 3 2
4 VF93011 Horizontal Beam 4 2
5 VF93012 T-Joint 6
6 VF93013 Vertical Leg 10
7 VF93028 Vertical Leg Cap 10
8 VF93014 L-Joint 4
9 VF93015 Screw Set-M5*30 8
10 VF93006 Drainage Valve Cover 1
11 VF93007 Stopper 2
12 VF93016 Pool Liner 1
13 VF93008
Drainage Valve Connector 1
