Vision X CG2-CPM310KIT - Component Details and Tips; Mounting and Adjustment Hardware Keys

8 pages

To Next Page

To Previous Page

3.7” CG2 LED MINI CANNON

(B2)

(Mounting Bracket)

ADJUSTMENT KEY

Part (B2) 5mm Locking Bolt

TIP: For complete application guide see website

MOUNTING KEY

Part (B1) Bolt [M8]

(Mounting Bracket)

Part (W1) Washer

Part (N1) Nut [M8]

(B1)

(W1)

(N1)

(Mounting Bracket)
