MAGNIFICATION & OPTICAL INFORMATION
PART
NUMBER
MAGNIFICATION RANGE
WITH 1.5x
MULTIPLIER
(C-040)
WITH 2x
MULTIPLIER
(C-041)
WORKING
DISTANCE
FIELD OF VIEW
AT MAX. ZOOM
FIELD OF VIEW
AT MIN. ZOOM
NOTES
C-050 x0.3 x2.1 - x12 x3.2 - x18 x4.2 - x24 312mm 12mm 77mm
Requires diverging lens when
used with 6 point ringlight
C-055 x0.5 x3.5 - x20 x5.3 - x30 x7.0 - x40 175mm 7mm 46mm
C-051 x0.7 x4.9 - x28 x7.4 - x42 x9.8 - x56 127mm 5mm 33mm
C-052 x1.0 x7.0 - x40 x10.5 - x60 x14 - x80 85mm 3.5mm 24mm
C-053 x1.5 x10.5 - x60 x15.8 - x90 x21 - x120 45mm 2.5mm 16mm Requires converging lens (Part
No. C-034) when used with 6
point ringlight
C-054 x2.0 x14 - x80 x21 - x120 x28 - x160 25mm 1.75mm 12mm
Note: Above figures without
multipliers fitted. To
calculate field of view =
140mm
magnification
MAGNIFICATION & OPTICAL INFORMATION
LYNX MAGNIFICATION TABLE
